Combination wave pulse 1, 2/50 - 8/20 µs (Hybrid-Surge pulse)
Pulse conforms to IEC/EN 61000-4-5 and ANSI (IEEE) 62.41

Teseq AG
Nordstrasse 11F 4542 Luterbach Switzerland
T + 41 32 681 40 40 F + 41 32 681 40 48
[email protected]

www.teseq.com

THE MODULAR SOLUTION FOR 6 KV APPLICATIONS

NSG 3060

691-130B August 2009

Parameter

Value

Pulse voltage (open circuit):

±200 V to 6.6 kV (in 1 V steps)

Pulse current (short circuit):

±100 A to 3.3 kA

Impedance:

2/12 Ω

Polarity:

positive / negative / alternate

Pulse repetition:

5* to 20 s, up to 600 s (in 1 s steps)

* derated depending on selected pulse voltage and

EUT supply voltage

Test duration:

1 to 9999 pulses, continuous

Phase synchronization:

asynchronous, synchronous 0 to 359º (in 1º steps)

Coupling:

ANSI / IEC / external

The NSG 3060 has an Ethernet port for external PC control. The Windows-based control software
simpliﬁ es test programming and allows compilation of complex test sequences with diverse pulse types.
Test reports can be generated during the test operation, allowing the operator to enter observations as
the test progresses and increasing the efﬁ ciency of long-term tests.

Ringwave 0.5 µs/100 kHz
Pulse conforms to IEC/EN 61000-4-12 and ANSI (IEEE) C62.41
