Detect power supply problems by
monitoring low frequency noise
on a segment. Locate incorrect
terminations and faulty devices by
diagnosing the communications
signal level.
For HART loops, the 475 Field
Communicator allows you to
verify whether the DC voltage
in the loop is correct.
an asset management system like
AMS Suite for in-depth analysis
and documentation.
Diagnose Network Problems
The 475 Field Communicator
can be used to configure all the
F
OUNDATION
fieldbus devices
in your plant. Use it to perform
diagnostics for effective start-up
and troubleshooting of fieldbus
segments. Create a quality
segment by diagnosing the
network DC voltage and
average noise.
Identify Valve Problems
Run valve diagnostics in the
field with the ValveLink Mobile
application. You can quickly
perform tests including valve
signature, dynamic error band,
and step response on HART
Fisher ® FIELDVUE ™ digital valve
controllers. ValveLink Mobile
does not currently support
F
OUNDATION
fieldbus devices.
The intuitive user interface makes
ValveLink Mobile easy to use and
understand. Diagnose issues in
the field or transfer the results to
Specifications
PROCESSOR AND MEMORY
Microprocessor
■
80 MHz Hitachi ® SH3
Memory Internal Flash
■ 32 MB
System Card
■ 1 GB secure digital card
RAM
■
32 MB
PHYSICAL
Weight
■ Approximately 1.65 lb. (0.75kg)
with battery
Display
■
1/4 VGA (240 by 320 pixels)
color, 3.5 in. (8.9 cm) transflective
display with touch screen
■
Anti-glare coated
Keypad
■ 25 keys including 4 action keys,
12 alphanumeric keys, tab key,
function key, backlight key, power key,
and 4 cursor-control (arrow) keys;
membrane design with tactile feedback
ENVIRONMENTAL
Usage
■
-10° C (14° F ) to +50° C (122° F )
■
0% to 95% RH (non-condensing)
for 0° C (32° F ) to +50° C (122° F )
Charge
■ 10° C (50° F ) to +40° C (104° F )
Storage With Batteries
■
-20° C (-4° F ) to +55° C (131° F )
Storage Without Batteries
■ -20° C (-4° F ) to +60° C (140° F )
Enclosure Rating
■ IP51 (from front)
Shock
■
Tested to survive a 1-meter
drop test onto concrete
EASY UPGRADE REQUIREMENTS
Usage
■ PC with Internet access
■ CD Rom drive
■
IrDA port (or adapter) or
Bluetooth (or adapter)
■
SD Card Reader (required for some
upgrades)
■
Windows XP (SP2 or SP3) or
Windows Vista Business (SP1)
POWER SUPPLY / CHARGER
Battery
■
Rechargeable Lithium-Ion power module
Battery Operating Time
■ 20 hours – continuous use
■ 40 hours – typical use
■ 80 hours – standby mode
Battery Charger Options
■
Input voltage 100-240 VAC, 50-60 Hz
■
Cables included with U.S., Europe,
and U.K. plugs
CONNECTION
Battery Charger
■
Mini DIN 6-pin jack
HART and Fieldbus
■ Three 4mm banana plugs (one common
to HART and F OUNDATION fieldbus)
IrDA Port
■ IrDA (Infrared Data Access) port
supporting up to 115 Kbps
■ ±15 degrees recommended maximum
angle from center line
■
Approximately 18 in. (45.7 cm)
recommended maximum distance
Bluetooth
■ Up to 32.8 ft. (10 m) communication
distance
■ Uses standard Windows drivers
■ FCC, IC, and CE approvals
Product Data Sheet
July 2010
