MODEL NO.
INPUT
VOLTAGE
CURRENT
OUTPUT
VOLTAGE - kV
CURRENT - mA
REGULATION
RIPPLE
ACCURACY
CONTROL UNIT
TYPE
HEIGHT
WIDTH
DEPTH
WEIGHT
HIGH VOLTAGE SECTION
INSULATION
HEIGHT
WIDTH
DEPTH
WEIGHT
801- 803- 805- 810- 825- 850- 875- 8100- 8120- 8150- 8200- 8300-
50A 16.6A 10A 5A 2A 1A 670 500 420 335 250 165
480 V 50/60 Hz*
480 V 50/60 Hz THREE PHASE* SINGLE PHASE
64A 110A
1 3 5 10 25 50 75 100 120 150 200 300
50A 16.6A 10A 5A 2A 1A 670 500 420 335 250 165
10% NL-FL 18%
5% rms (1% OPTIONAL) 2% rms
2% FS
CABINET
70 in (1778 mm)
23 in (584 mm)
25 in (635 mm)
850 lb (386 kg)
AIR OIL
30 in 32 in 35 in 48 in
(762 mm) (813 mm) (869 mm) (1219 mm)
40 in 44 in 54 in
(1016 mm) (1118 mm) (1372 mm)
28 in 30 in 40 in
(711 mm) (762 mm) (1016 mm)
5400 lb 5600 lb 6200 lb 6250 lb 6500 lb 7000 lb
(2449 kg) (2540 kg) (2812 kg) (2835 kg) (2948 kg) (3175 kg)
70 in
(1778 mm)
23 in
(584 mm)
25 in
(635 mm)
2500 lb
1000 lb (454 kg)
SPECIFICATIONS FOR 50 KW HIGH POWER DC POWER SUPPLIES
*380 or 415 Volt, 50 Hertz also available
