Technical Data
Ordering Information
Headquarter Germany
Oerlikon
Leybold Vacuum GmbH
Bonner Strasse 498
D-50968 Köln
T +49 (0) 221-347-0
F +49 (0) 221-347-1250
[email protected]
OM 09056.02
2.x.03.07 pe
ed
in
Germany
on
chlorine-fr
ee
bleached
p
aper
Technical
alterations
reserved
Helium Leak Detector PHOENIXL 300 300 Dry 300 Modul
Lowest detectable helium leak rate
Vakuum operation mbar l/s ≤ 5 · 10 -12 ≤ 3 · 10 -11 ≤ 5 · 10 -12 a) / 8 · 10 -12 b)
Sniffer operation mbar l/s ≤ 1 · 10 -7 ≤ 1 · 10 -7 ≤ 1 · 10 -7
Maximum measurable helium leak rate
Vakuum operation mbar l/s > 0.1 > 0.1 > 0.1
Measurement ranges 12 decades 12 decades 12 decades
Maximum permissible inlet pressure mbar 15 15 15
Pumping speed during pumpdown,
50 Hz/ 60 Hz m 3 /h 2.5 / 3 1.6/1.8 25/30a) / 30/36 b)
Helium pumping speed in the vacuum mode l/s > 2.5 > 2.5 > 2.5
Time constant for the leak rate signal s < 1 < 1 < 1
Time until ready for operation min ≤ 2 ≤ 2 ≤ 2
Power consumption VA 420 350 350
Inlet flange DN 25 KF DN 25 KF DN 25 KF
Dimensions (W x H x D) mm 495 x 456 x 314
Weight kg 40 35.5 29.5
a) with rotary vane pump TRIVAC D 25 B 25 m3/h
b) with scroll pump 30 m3/h
Ordering Information PHOENIXL 300 300 Dry 300 Modul
Helium leak detector PHOENIXL
230 V, 50/60 Hz Euro model 250 000 250 001 250 002
115 V, 60 Hz US model 251 000 251 001 250 002
100 V, 50/60 Hz Japan model 251 100 251 101 250 002
Remote control kit, consisting of
remote control unit, 4 m cable, mounting kit 252 002 252 002 252 002
Extension cable for remote control, 8 m 140 22 140 22 140 22
Sniffer line SL300, 4 m 252 003 252 003 252 003
LeakWare - data acquisition software 140 90 140 90 140 90
Partial flow system, 90 V / 230 V, AC, 50/60 Hz 140 20 – 140 20
Transport case 252 004 252 004 252 004
Mobile Cart model according to a customer specs. upon request upon request upon request
* not for shipping. Use as a transport or storage case only.
