SmartClaSS Home v3
Product specifications and descriptions in this document subject to change without notice. © 2011 JDS Uniphase Corporation 30162605 001 0611 SMCLASSHFULL.DS.CAB.TM.AE June 2011
ordering information
model Part number Description
SmartClass Home V3 SC-Home-V3 xDSL, HPNA, and inside wiring test tool for coax and twisted pair with included butt-set, WiFi, and Ethernet verification tools
SmartClass Home HPNA SC-Home-HPNA HPNA, and inside wiring test tool for coax and twisted pair with included butt-set, WiFi, and Ethernet verification tools
accessories
Active IDs 1-8 SC-HOME-IDSET-V3 Active IDs 1-8 for identifying single or multiple coax run locations. Works through splitters.
CB-5CLIP-BON RJ-45 to telco clips (5) bonded DSL cable
CB Bonded RJ to RJ bonded DSL cable
6-pin Banjo SCHM6PINADAPTER 6-pin adapter—6-pin banjo—Breaks out POTS connection for use with alligator clips
Toning Wand SCHMTONERTRACER Toner Tracer wand TT100
Vehicle Charger SCHMCARCHGR 12 VDC vehicle charger adapter
replacement accessories
SCDVOMTELCOCLIPS DVOM Mini Banana to telco clips
Coax Resistive IDs SCHMCOAXRESID Replacement coax resistive IDs 1-8 for locating single coax runs
Active IDs 1-8 SC-HOME-IDSET-V3 Active IDs 1-8 for identifying single or multiple coax run locations. Works through splitters.
Ethernet Resistive IDs SCHMRJ45RESID Replacement RJ45 resistive IDs 1-8 for locating single Ethernet runs
Phone Resistive IDs SCHMRJ11RESID Replacement RJ11 resistive IDs 1-8 for locating single POTS runs
Phone Patch Cable SCHMRJ11 PATCH Replacement RJ11 8-in patch cable
Ethernet Patch Cable SCHMRJ45PATCH Replacement RJ45 12-in patch cable
Phone to Coax Adapter SCHMRJ11TOCOAX Replacement RJ11-to-coax adapter cable for toning
Strand Hook SCHMSTRANDHOOK Replacement Stand Hook—clip to hold or hang unit
Smart Remote SCHMSMARTREMOTE Replacement SmartRemote—yellow RJ11 and RJ45 used to map out twisted pair connections
NIT Antenna SCHMANTENNA Replacement antenna for NIT calibrating off-air FM frequencies
Large Carrying Case SC-HOME-BAG-V3 Replacement large carrying case for unit and accessories
Replacement Battery SCHMLIONBATT4 Standard lithium ion battery for replacement or spare
Replacement Charger SCHMCHARGER Replacement AC charger—power supply and cable
Replacement Sleeve SCHMSLEEVE Replacement protective canvas sleeve to cover the unit
Butt-Set
North American POTS Butt-Set Only
Features
Supports loop start dial tone POTS testing on twisted pair
Supports receiving a call
Supports line monitor mode with DTMF decode
Supports caller ID, call waiting, with caller ID errors
Microphone and speakerphone support
Measures voltage from 0 to 105 V, ±4%
Measures loop current from 14 to 108 mA ±4%
Specifications and Features (Continued)
General
Power Supply
Field replaceable, rechargeable lithium ion battery
Operating time approximately 4.5 hrs continuous (typical)
Charging time, internal 4-5 hrs from empty to full charge
DC input 12 V, 1.25 A
100/240 V, 50/60 Hz auto-sensing AC adapter for line
operation and charging
Permissible ambient temperature
Nominal range of use –5 to +50°C (23 to +120°F)
Storage and transport –30 to +60°C (–22 to ±140°F)
Humidity
Operating humidity 10 to 80% RHNC
Physical Specifications
4 in 320x240 high visibility color display
USB 2.0 interface for upgrades and data transfer
Full telephone keypad for fast access and dialing
