JD745A CELLADVISOR BASE STATION ANALYZER
Bias Tee (Option 002)
Voltage
Voltage range +12 to +32 V
Voltage resolution 0.1 V
Power
8 W Max
CW Signal Generator (Option 003)
Frequency
Frequency range 25 MHz to 4 GHz
Frequency reference ±25 ppm Maximum
Frequency resolution 10 kHz
Output Power
Range 0 dBm, –30 to –80 dBm
Step 1 dB
Accuracy ±1.5 dB (15 to 35°C)
GPS Receiver and Antenna (Option 010)
GPS Indicator
Latitude, longitude, altitude
High-Frequency Accuracy
Spectrum, interference, and signal analyzer
GPS lock
±25 ppb
Hold over (for 3 days) ±50 ppb (0 to 50°C) 15 minutes after
satellite locked
Connector SMA, female
Interference Analyzer (Option 011)
Measurements
Spectrum analyzer Sound indicator, AM/FM audio demodulation,
interference ID, spectrum recorder
Spectrogram Collect up to 72 hours of data
RSSI Collect up to 72 hours of data
Interference finder
Spectrum replayer
Dual spectrogram
Channel Scanner (Option 012)
Frequency Range
10 MHz to 4 GHz
Measurement Range
–110 to +20 dBm
Measurements
Channel scanner 1 to 20 channels
Frequency scanner 1 to 20 frequencies
Custom scanner 1 to 20 channels or frequencies
