JD745A CELLADVISOR BASE STATION ANALYZER

E1 Analyzer (Option 004)

Electrical Interface

Connectors RX/TX

RJ45 (120 Ω)

Output

0 dB, –6 dB (ITU-T Rec.G.703)

Line code

AMI, HDB3

Impedance

Term, monitor 120 Ω,
bridge >1000 Ω

Input

Term/bridge/monitor

0 to −20 dB

Transmitter and Receiver

Framing

PCM-30, PCM-30 with CRC
PCM-31, PCM-31 with CRC

Channel formats

Full E1

Test pattern

1-4, 1-8, ALL1, ALL0, 0101

Additional Functions

Reference clock

Received or internal

Event log capability

Internal memory

Error insertion

1, 1E–3, 1E–4, 1E–5

Error rate count

CRC, frame, code, bit

Measurements

Monitoring

BERT

Indicators

Indicators

E1 signal
Frame sync
Pattern sync
Code sync
FAS RAI
AIS
HDB3
Bit error

2

E1 signal
Frame sync
Pattern sync
Code sync
FAS RAI
AIS
HDB3
Bit error

2

Error count/rate

Error count/rate

Frame error
Code error
Bit error

2

CRC error

1

Frame error
Code error
Bit error

2

Alarm count

Alarm count

FAS
AIS

FAS
AIS

Loss count

Loss count

Frame sync
Pattern sync

Frame sync
Pattern sync

1. When CRC-4 is set to On.

2. When PCM31 is set to On.

T1 Analyzer (Option 005)

Electrical Interface

Connectors RX/TX

RJ45 (120 Ω)

Output

0 dB, –7.5 dB, –15 dB

Line code

AMI, B8ZS

Impedance

100 Ω or 1000 Ω
(bridge)

Input

Term/bridge/monitor

0 to −20 dB

Transmitter and Receiver

Framing

D4, ESF

Channel formats

Full T1

Test pattern

1–8, 1–16, ALL1, ALL0, 0101
2E–24, QRSS, 2E–23, 2E–15,
2E–23 inverse, 2E–15 inverse

Additional Functions

Reference clock

Received or internal

Event log capability

Internal memory

Error insertion

1, 1E–3, 1E–4, 1E–5

Alarm insertion

AIS, RAI

Error/alarm count

Bit RAI, AIS, BPV, BER

Loopback modes

Self, CSU, NIU, line, network

Measurements

Monitoring/BERT/loop test

RX signal level

Indicators

Indicators

T1 signal
Frame sync
Pattern sync
B8ZS
Red alarm
RAI (yellow alarm)
AIS (blue alarm)
BPV indicator

T1 signal
Frame sync
Pattern sync
B8ZS
Red alarm
RAI (yellow alarm)
AIS (blue alarm)
BPV indicator

Loss count

Vp-p

Signal loss
Frame sync loss
Patten sync loss

Vp-p Max
Vp-p Min
dB

dsx

Alarm count

RAI
AIS
BPV

Error rate

Bit error rate
Bit error count

Wireless Connectivity (Option 006)

Bluetooth Connectivity

Personal area networking (PAN)
File transfer protocol (FTP)
