Electric and Magnetic Field Measurement
543
USA TEL: (1) 631 231-1700 • INT’L TEL: (1) 631 231-1390 • FAX (1) 631 231-1711
E-MAIL: [email protected] • www.nardamicrowave.com
FREQUENCY
SENSITIVITY a,b
ISOTROPIC c
RESPONSE
CW
OVERLOAD
(mW/cm 2 )
PEAK
OVERLOAD
(W/cm 2 )
CALIBRATION c
FREQUENCIES
APPROX
WEIGHT
oz/kg
OUTLINE
DRAWING
± 0.75 dB ± 0.5 dB
600
600
0.3, 0.5, 1, 3,
10 MHz
12/0.34 2
6000
1000
± 1.5 dB from standard ± 0.5 dB
900% of
Standard
30 dB above
Standard
0.3, 1, 3, 10, 30,
100, 200 MHz
12/0.34 2
± 0.5 dB (13 MHz to
200 MHz)
2 dB Max deviation
(10 MHz to 300 MHz)
± 0.5 dB
60 20
10, 13.56, 27.12,
40.68, 50, 75
100, 150, 200,
250, 300 MHz
12/0.34 2
300 300
CONNECTOR USE
EQUIPMENT MODEL TYPE GENDER
8718B, 8715, 8712 Meters L Female
8717 Series Meters A Female
8700D Series Probes L Male
8747 Fiber Optic Link L Female
8718, 8716, 8711 Meters A Female
8700 Series Probes (Except D Series) A Male
8745, 8745T, 8746 Fiber Optic Links A Female
USE OF OLDER STYLE PROBES WITH
NEW METERS
A special adaptor cable is required to connect older style
8700 probes with the type A connector and integral cable
to the current hand-held meters that feqture the quick re-
lease type L connector. The part number of this 1 ft. (30
cm) type L male to type A female cable is 21787700.
PROBE EXTENSION CABLES
MODEL LENGTH
MALE
CONNECTOR
FEMALE
CONNECTOR
8740-04 4 ft. (1.2 m) Type A Type A
8740-06 6 ft. (1.8 m.) Type A Type A
8740-12 12 ft. (3.7 m.) Type A Type A
8740-24 24 ft. (7.3 m.) Type A Type A
8740-40 40 ft. (12.2 m.) Type A Type A
8743-04 4 ft. (1.2 m.) Type A Type L
8744-04 4 ft. (1.2 m.) Type L Type L
8744-12 12 ft. (3.7 m.) Type L Type L
