4
Your budget is
limited – your test
equipment doesn’t
have to be.
Now you can get the speed and
accuracy you need and still have
money left in your budget. The
Agilent ESA-L series portable
spectrum analyzers have a remark-
able four-millisecond RF sweep time
and virtual real-time measurement
updates to the display or through
GPIB interface. With excellent accu-
racy and easy, reliable operation,
the ESA-L series is full of innova-
tions, such as continuously phase-
locked synthesizer, all at a
surprisingly low cost.
Frequency Frequency Phase noise Residual FM Resolution Maximum Overall Maximum Measurement
range accuracy (10 kHz offset) bandwidth amplitude amplitude dynamic rate
9 kHz to: (at 1 GHz) range range accuracy range (characteristic)
(2 nd /3 rd order)
E4411B 1.5 GHz ±2 kHz ≤–90 dBc/Hz ≤150 Hz 1 kHz to –119 ±1.1 dB ≥76 dB/83 dB ≥28 updates/sec
E4403B 3 GHz peak to peak 5 MHz –117 ≥79 dB/83 dB
E4408B 26.5 GHz –116 ≥78 dB/82 dB
to +30 dBm
Specification summary
Designed for performance measurements
• Fast measurements
• Accurate results
• Rugged and reliable
• Quick and easy to use
E4411B
E4403B
E4408B
9 kHz 1.5 GHz 3 GHz 26.5 GHz
For complete specifications, see page 10. Ordering information is shown on page 13.
Available frequency ranges
