135
Spectrum Analyzers
16-Bit Resolution, 100 kHz Portable Type
R9211Series
Digital output: Internal A/D converter data is output
Data format: 16 bit + channel identifier signal + strobe signal
(offset binary)
Comparator output: (R9211C) Comparator function output is
possible using O/C output
CMOS Memory Function
1 M words (2 M bytes) battery backup memory
Thermal Printer
Hard copy of CRT screen
Printing method: Thermal line/dot method
Dot configuration: 640 dots/line
Paper used: A09075
Paper width: 114 mm
High speed calculation processor functions
High speed numerical calculations
Running Zoom Analysis Function (R9211A/9211C)
When the stop frequency is less than 10 kHz, the minimum span is
10 mHz. When the stop frequency is 10 kHz or more, zoom analysis
can be done with a minimum span of 100 mHz.
General Specifications
Operating conditions: Temperature +5 to +35˚C, RH 80% max.
Storage conditions: Temperature -20 to +60˚C
Power supply: Specify at time of ordering
48 to 66 Hz
Power consumption: Standard
External dimensions: Approx. 330 (W) × 177 (H) × 450 (D) mm
Mass: Main unit
Accessories
Power Cable: A01402 (one)
Input Cables: MI-77 (two)
T-Type Connector
Accessories (Sold Separately)
A02804
Front Cover
R16211 Carrying Case
R16055 Transit Case
A02034 Panel Mount Set
A02255 Rack Mount Set (JIS standard)
A02455 Rack Mount Set (EIA standard)
R9211E R9211A R9211B R9211C
Option 10 Option 10 Option 10 Option 10
R9211E R9211A R9211B R9211C
Option 07 Option 07 Option 07 Option 07
R9211E R9211A R9211B R9211C
— Option 12 — Standard
Option no. Standard 32 42 44
Power voltage (V) 90 to 110 103 to 132 198 to 242 207 to 250
R9211E R9211A R9211B R9211C
140 VA max. 160 VA max. 170 VA max. 190 VA max.
R9211E R9211A R9211B R9211C
12 kg max. 14 kg max. 14 kg max. 16 kg max.
