134
Spectrum Analyzers
Choice of 4 Types To Fit the Application
R9211Series
(Continued From Previous Page)
Marker analysis functions: Peak marker, next peak marker, band
marker, harmonics marker, sideband marker, overall power, partial
power, average power, dispersion, + peak marker, - peak marker, X
dB marker, shape factor marker, ripple marker, open loop Bode
diagram marker, open loop gain marker
Calculation functions: Basic arithmetic, unwrapped phase, jw, 1/jw,
reciprocal, impulse response, equalize, phase correction, COP (co-
herent output power), open/closed loop conversion
Display functions: Frequency/amplitude, frequency/phase, frequency/
real number component, frequency/imaginary number component,
frequency/ group delay, frequency/associativity function, Nyquist
diagram, Cole-Cole diagram, Nichols diagram
Curve Fitting Function
Up to 20 groups of range poles and zeroes are sampled from
frequency response function data
Weighting: Auto weight, uniform weight, user weight
Conversion function: Sampled range poles and zeroes can be con-
verted to range poles and residue or polynomials
Synthesis Function
Frequency response function, impulse response and step response
can be synthesized from sampled range poles and zeroes or values of
entered range poles and zeroes.
Signal generator (R9211B/9211C) Except for servo analysis mode
Output waveform: Sine wave (spot), swept sign, multi-sign, impulse,
random, user selected waveform (max. memory size: 64 K words)
Maximum output voltage: ± 15 V (at 1 Ω max. output impedance)
Maximum output current: 100 mA (at 1 Ω max. output impedance)
DC offset: ± 10 V (0.1 V resolution)
Output impedance: 1 Ω max., 50 Ω, 600 Ω
Output modes: Continuous, internal, external, external gate, manual
Taper function: 200 ms max.
Summation amplifier: Can be turned on or off
Running zoom function: (R9211A/9211C)
When the stop frequency is less than 10 kHz, the minimum span is
10 mHz. When the stop frequency is 10 kHz or more, zoom analysis
can be done with a minimum span of 100 mHz.
Comparator Function (R9211C)
Setting modes: Table mode, reference mode
Table mode: Up to 20 groups of comparative sections can be set
Reference mode: Comparator can be done against a reference
waveform
Target waveform: Comparator can be done against frequency
domain data
Comparator results:
• PASS/FAIL displayed on screen
• Buzzer
• Output from rear by TTL O/C
Display Specifications and Functions
Display functions: 8-inch raster scan CRT
Engineering units: Marker readout values and vertical axis scaling can
be displayed as freely specified physical quantities
Scaling: Linear/log scaling, scaling can be done independently for each
channel
Units: Up to any 2 characters among those specified can be set
Display modes: 1, 2, 3 or 4 screen display
Overlapping display mode: Data in the same domain or analysis
range can be displayed in overlapping format
Lattice display: Can be turned on or off
R9211E R9211A R9211B R9211C
Memory (128 K words) Standard Standard Standard -
I/O + memory (1 M words) Option 11 Option 11 Option 11 Standard
CMOS memory (1 M words) Option 10 Option 10 Option 10 Option 10
R9211E R9211A R9211B R9211C
Option 06 Standard Standard Standard
3-D display: Up to 50 lines of the desired display data can be displayed
in 3-D
Bar display: Overall power, partial power, average power or power
dispersion can be shown as a bar display at the right edge of the CRT
screen
Labels: Up to 40 alphanumeric or special characters can be displayed
and moved up and down
List modes:
Single mode 20 spectrum frequency values and level values in
the display can be selected by cursor and listed in a digital
display
Harmonics mode When the basic spectrum is set by entering the
values, the level values are listed in a digital display, and THD
(total harmonic distortion) and THP (total harmonic power) are
calculated and displayed.
Sideband mode When carrier frequency and modulated signal
frequency are set by entering the values, the upper waveband
and lower waveband power up to the 10th degree is calculated
and displayed
Horizontal axis: Linear, log
Vertical axis: Can be freely set by entering the values
Calendar/clock function: Calendar (year/month/day) and hour/
minutes display
Memory function:
Transient waveform data memory: In time/frequency analysis mode
Panel memory: Remembers panel settings (battery backup, settings
last about 1 month)
Input/Output Functions
GPIB interface: Provided as standard
Plotter output: Direct plotting can be done with any ADVANTEST
plotter with a GPIB interface, or a plotter with HPGL function and
GPIB cable
External sampling clock input: BNC type, TTL level
External trigger input: BNC type, TTL level
Sampling clock output: BNC type, TTL level
Trigger output signal: BNC type, TTL level
Floppy Disk Drive
Type: 3.5 inch micro floppy disk
Media: 2DD/2HD (automatically identified)
Capacity: 720 K/1.2 M bytes (when formatted)
Format: Can be converted to MS-DOS format
File format: Data file, view file, table file
Data file operations: List, create, erase, search, copy
I/O + Memory Function
Memory capacity: 1 M words (2 M bytes)
Digital input: Digital input can be done with the internal A/D con-
verter, or an external digital signal (max. sampling rate 256 kHz)
Data format: 16 bit + EOC signal (offset binary)
R9211E R9211A R9211B R9211C
Option 11 Option 11 Option 11 Standard
