22
Speciications
R E V O L U T I O N A R Y S I G N A L F I D E L I T Y W I T H U N M A T C H E D C A P A B I L I T I E S
Environmental
Storage temperature –40 to 70 ºC
Warm-up time 1 hour
Operating environment eN61010, pollution degree 2, indoor locations
Operating temperature 0 to 55 ºC
Operating humidity 5% to 80% Rh, non-condensing
Operating altitude < 3000 meters
Regulatory
Refer to the Declaration of Conformity, which can be viewed and downloaded from
http://regulations.corporate.agilent.com/DoC/search.htm
Sound pressure level (1-m free-field) (nom) 35 dB(a) at t
aMBIeNt
≤ 28 ºC
Line power
Line voltage 100 to 240 V, 50/60 hz
100 to 120 V, 400 hz
Power consumption 75 W, 150 Va
Warranty
Standard 3 years
General characteristics, continued
FOOTNOTES
1. Applies to 120-MHz models (33621A/22A) only.
2. DC Offset set to zero.
3. Add 1/10 of the specification per ºC for operation at temperatures below 18 ºC or above 28 ºC.
4. At low amplitude, non-harmonic spurious level is -100 dBm (typ).
5. Measured with an Agilent E5052B signal source analyzer. Phase noise improves by 20 dB/decade as output frequency is decreased.
6. Subject to pulse width limits.
7. Measured with an Agilent E5052B signal source analyzer.
8. Maximum sample rate with Filter “Off” is 160 MSa/s for 80-MHz models and 250 MSa/s for 120-MHz models.
9. Maximum amplitude is less at high frequency for certain waveforms.
10. Counted burst is not available for Gaussian Noise.
11. Subject to amplitude limits.
12. All frequency changes are phase-continuous.
13. External trigger only for sweep time > 8000 s.
14. Measured with a Square or Pulse waveform, edge time set to minimum, and trigger delay set to zero. Trigger latency is generally greater
for other instrument settings. For some waveforms, trigger latency is a function of output frequency.
