SPECIFICATIONS

61500-E-201108-2000

Worldwide Distribution and Service Network

Distributed by:

JAPAN

CHROMA JAPAN CORP.

472 Nippa-cho, Kouhoku-ku,

Yokohama-shi, Kanagawa,

223-0057 Japan

http://www.chroma.co.jp

E-mail: [email protected]

U.S.A.

CHROMA SYSTEMS

SOLUTIONS, INC.

25612 Commercentre Drive,

Lake Forest, CA 92630-8830

Tel: +1-949-600-6400

Fax: +1-949-600-6401

Toll Free: +1-866-600-6050

http://www.chromausa.com

E-mail: [email protected]

Developed and Manufactured by :

CHROMA ATE INC.

致茂電子股份有限公司

HEADQUARTERS

No. 66, Hwa-Ya 1st Rd.,

Hwa-Ya Technology Park,

Kuei-Shan Hsiang,33383

Taoyuan County, Taiwan

Tel: +886-3-327-9999

Fax: +886-3-327-8898

http://www.chromaate.com

E-mail: [email protected]

EUROPE

CHROMA ATE EUROPE B.V.

Morsestraat 32, 6716 AH Ede,

The Netherlands

Tel: +31-318-648282

Fax: +31-318-648288

http://www.chromaeu.com

E-mail: [email protected]

CHINA

CHROMA ELECTRONICS

(SHENZHEN) CO., LTD.

8F, No.4, Nanyou Tian An

Industrial Estate, Shenzhen,

China PC: 518052

Tel: +86-755-2664-4598

Fax: +86-755-2641-9620

Model

61501

61502

61503

61504

61505

Output Phase

Output Rating -AC
Power

500VA

1000VA

1500VA

2000VA

4000VA

Voltage
Range/Phase

150V/300V/Auto

Accuracy

0.2%+0.2%F.S.

Resolution

0.1V

Distortion*1

0.3% @ 50/60Hz

1% @ 15-1kHz (Typical)

0.3% @ 50/60Hz

1% @ 15-1kHz (Typical)

0.3% @ 50/60Hz

1% @ 15-1kHz (Typical)

0.3% @ 50/60Hz

1% @ 15-1kHz (Typical)

0.3% @ 50/60Hz

1% @ 15-1kHz (Typical)

Line Regulation

0.1%

Load Regulation*2

0.2%

Max. Current
R.m.s.

4A/2A (150V/300V)

8A/4A (150V/300V)

12A/6A (150V/300V)

16A/8A (150V/300V)

32A/20A (150V/300V)

Peak

24A/12A (150V/300V)

48A/24A (150V/300V)

72A/36A (150V/300V)

96A/48A (150V/300V)

192A/96A (150V/300V)

Frequency
Range

DC, 15 ~ 1kHz

Accuracy

0.15%

Output Rating-DC
Power

250W

500W

750W

1000W

2000W

Voltage

212V/424V

Current

2A/1A (212V/424V)

4A/2A (212V/424V)

6A/3A (212V/424V)

8A/4A (212V/424V)

16A/8A (212V/424V)

Programmable Output Impedance
Range

0Ω +200µH ~ 1Ω +1mH

Harmonics & Inter-harmonics Simulation
Bandwidth

2400Hz

Input Rating
Voltage Range

90~250V, 1Ø

190~250V, 3Ø*3

Frequency Range

47~63Hz

Current (per phase)

10A Max. @ 90V

18A Max. @ 90V

22A Max. @ 90V

28A Max. @ 90V

14A Max. @ 190V

Power Factor*4

0.97 Min.

0.98 Min.

Measurement
Voltage
Range

150V/300V

Accuracy

0.2%+0.2%F.S.

Resolution

0.1V

Current
Range (peak)

24A

48A

72A

96A

192A

Accuracy (r.m.s.)

0.4%+0.3%F.S.

Accuracy (peak)

0.4%+0.6%F.S.

Power
Accuracy

0.4%+0.4%F.S.

Resolution

0.1W

Harmonics
Range

2~40 orders

Others
Interface

GPIB, RS-232 (Optional)

Temperature
Operating

0 ~ 40˚C

Storage

-40 ~ +85˚C

Safety & EMC

CE ( include EMC & LVD )

Dimensions
(HxWxD)

133.35 x 482.6 x 569.5 mm /

5.25 x 19 x 22.42 inch

133.35 x 482.6 x 569.5 mm /

5.25 x 19 x 22.42 inch

133.35 x 482.6 x 569.5 mm /

5.25 x 19 x 22.42 inch

133.35 x 482.6 x 569.5 mm /

5.25 x 19 x 22.42 inch

266.7 x 482.6 x 569.5 mm /

10.5 x 19 x 22.42 inch

Weight

20 kg / 44.05 lbs

41 kg / 90.31 lbs

Note*1 : Maximum distortion is tested on output 125VAC (150V RANGE) and 250VAC (300V RANGE) with maximum current to linear load.
Note*2 : Load regulation is tested with sine wave and remote sense.
Note*3 : Model 61505 can also use single-phase connecting method of input AC power, the maximum input current is 28A @ 190V.
Note*4 : Input power factor is tested on input 220V, full load condition.
