Atec Chroma-61600 Series - Manual (Page 4)

All specifications are subject to change without notice.
SPECIFICATIONS
Distributed by:
Worldwide Distribution and Service Network
61600-201009-2000
Note 1 : Maximum distortion is tested on output 125VAC (150V RANGE) and 250VAC (300V RANGE) with maximum current to linear load.
Note 2 : Load regulation is tested with sinewave and remote sense.
Note 3 : Input power factor is tested on input 220V, full load condition.
Model 61601 61602 61603 61604 61605
Output Phase 1 1 1 1 1
Output Rating-AC
Power/Phase 500VA 1000VA 1500VA 2000VA 4000VA
Voltage
Range/Phase
150V/300V/Auto 150V/300V/Auto 150V/300V/Auto 150V/300V/Auto 150V/300VAuto
Accuracy 0.2%+0.2%F.S. 0.2%+0.2%F.S. 0.2%+0.2%F.S. 0.2%+0.2%F.S. 0.2%+0.2%F.S.
Resolution 0.1V 0.1V 0.1V 0.1V 0.1V
Distortion*1 0.3% @ 50/60Hz1%,
15-1KHz (Typical)
0.3% @ 50/60Hz1%,
15-1KHz (Typical)
0.3% @ 50/60Hz1%,
15-1KHz (Typical)
0.3% @ 50/60Hz1%,
15-1KHz (Typical)
0.3% @ 50/60Hz1%,
15-1KHz (Typical)
Line Regulation 0.1% 0.1% 0.1% 0.1% 0.1%
Load Regulation *2 0.2% 0.2% 0.2% 0.2% 0.2%
Max. Current/Phase
R.m.s.
4A/2A (150V/300V) 8A/4A (150V/300V) 12A/6A (150V/300V) 16A/8A (150V/300V) 32A/20A (150V/300V)
Peak 24A/12A (150V/300V) 48A/24A (150V/300V) 72A/36A (150V/300V) 96A/48A (150V/300V) 192A/96A (150V/300V)
Frequency
Range
DC,15-1KHz DC,15-1KHz DC,15-1KHz DC,15-1KHz DC,15-1KHz
Accuracy 0.15% 0.15% 0.15% 0.15% 0.15%
Output Rating-DC
Power 250W 500W 750W 1000W 2000W
Voltage 212V/424V 212V/424V 212V/424V 212V/424V 212V/424V
Current(per phase) 2A/1A (212V/424V) 4A/2A (212V/424V) 6A/3A (212V/424V) 8A/4A (212V/424V) 16A/8A (212V/424V)
Programmable Output Impedance
Range 0 Ω+200µH ~ 1Ω+1mH
Harmonics & Inter-harmonics Simulation
Bandwidth 2400Hz 2400Hz 2400Hz 2400Hz 2400Hz
Input Rating
Voltage Range 90-250V, 1ø 90-250V, 1ø 90-250V, 1ø 90-250V, 1ø 190-250V, 3ø
Frequency Range 47-63Hz 47-63Hz 47-63Hz 47-63Hz 47-63Hz
Current(per phase) 10A Max. @ 90V 18A Max. @ 90V 22A Max. @ 90V 28A Max. @ 90V 14A Max. @ 190V
Power Factor *3 0.97 Min. 0.97 Min. 0.98 Min. 0.98 Min. 0.98 Min.
Measurement
Voltage
Range/Phase
150V/300V 150V/300V 150V/300V 150V/300V 150V/300V
Accuracy 0.2%+0.2%F.S. 0.2%+0.2%F.S. 0.2%+0.2%F.S. 0.2%+0.2%F.S. 0.2%+0.2%F.S.
Resolution 0.1V 0.1V 0.1V 0.1V 0.1V
Current
Range(peak)
24A 48A 72A 96A 192A
Accuracy(r.m.s.) 0.4%+0.3%F.S. 0.4%+0.3%F.S. 0.4%+0.3%F.S. 0.4%+0.3%F.S. 0.4%+0.3%F.S.
Accuracy(peak) 0.4%+0.6%F.S. 0.4%+0.6%F.S. 0.4%+0.6%F.S. 0.4%+0.6%F.S. 0.4%+0.6%F.S.
Power
Accuracy
0.4%+0.4%F.S. 0.4%+0.4%F.S. 0.4%+0.4%F.S. 0.4%+0.4%F.S. 0.4%+0.4%F.S.
Resolution 0.1W 0.1W 0.1W 0.1W 0.1W
Others
Interface GPIB,RS-232 (Optional)
Temperature
Operating
0~40˚C 0~40˚C 0~40˚C 0 ~ 40˚C 0 ~ 40˚C
Storage -40~+85˚C -40~+85˚C -40~+85˚C -40~+85˚C -40~+85˚C
Safety & EMC CE (Include EMC & LVD)
Dimensions(WxHxD) 482 x 132.6 x 570mm 482 x 132.6 x 570mm 482 x 132.6 x 570mm 482 x 132.6 x 570mm 482 x 265.9 x 570 mm
Weight 20 kg 20 kg 21 kg 21 kg 36 kg
