MODEL 3003 3006 3009 3015 3030 3060 3090
INPUT SPECIFICATIONS
Phase 1Ø/2W + ground 3Ø/3W + ground
Voltage 230V±15% 220, 240, 380, 415, 480V±10%
Frequency 47-63Hz
OUTPUT SPECIFICATIONS
Power rating
Total Power 3kVA 6kVA 9kVA 15kVA 30kVA 60kVA 90kVA
Per Phase 1kVA 2kVA 3kVA 5kVA 10kVA 20kVA 30kVA
Max Arms per Ø @ 0-150 V 8.4 A 16.8 A 25.2 A 42.0 A 84.0 A 168.0 A 252.0 A
Max Arms per Ø @ 0-300 V 4.2 A 8.4 A 12.6 A 21.0 A 42.0 A 84.0 A 126.0 A
Phase 3Ø/5W
Voltage
Line to Neutral 0-150V/0-300V Selectable
Line to Line 0-260V/0-520V Selectable
Resolution 0.1V
Accuracy ±(1%+0.2V)
Frequency
Range 45-500Hz
Resolution 0.1Hz at 45-99.9Hz, 1Hz at 100-500Hz
Accuracy ±0.2%
Harmonic Distortion ≤1%(Resistance Load)
Crest Factor ≥3 to 1
Load Regulation ±0.5%
Protection Over Current, Short Circuit, Over Temperature
Efficiency ≥85% (at full load)
Operating Temperature 32°-104°F, (0°-40°C), 80% Relative Humidity
Altitude below 6500 feet
DISPLAYS AND CONTROLS
4 Digital LED meters Frequency, Voltage, Current, Power or Power Factor (simultaneously)
PLC Remote Interface P1, P2, P3, and Output On/Off
Memory 3 Programmable Memory Locations for Voltage, Frequency and Current
Calibration Front Panel Calibration
Interface (optional) GPIB, or RS-232
Auto voltage adjust Enable for improved voltage regulation within ±0.1V
MECHANICAL SPECIFICATIONS
3kVA 6kVA 9kVA 15kVA 30kVA 60kVA 90kVA
Dimensions (HxDxW) Inches 29x26x17 29x26x17 32x36x24 32x36x24 38x36x24 55x36x24 71x36x48
Weights (Kg/lbs) 105/230 120/265 220/485 290/640 460/1010 760/1675 1200/2640
©2003 ADAPTIVE POWER SYSTEMS, Irvine, CA, U.S.A. Subject to change without notice.
Cooling fans
Output curcuit breaker
Output connections
Input curcuit breaker
801 Hailey Street Ardmore, OK 73401
Direct: 949-752-8400 • Fax: 949-756-0838
Toll Free: 1-866-517-8400
www.adaptivepower.com
TM
APS3000-9/06
Instrument Specifications
Input connections
Casters
