4
Ordering Information
E3630 Series Power Supplies
E3631A 80-Watt
Triple Power Supply
E3632A 120-Watt
Single Power Supply
E3633A/34A 200-Watt
Single Power Supply
Standard Shipped Accessories
User’s & Service guide, Product
Reference CD, AC power cord
Power Options
Opt. 0E3 230 Vac ± 10%
Opt. 0EM 115 Vac ± 10%
Opt. 0E9 100 Vac ± 10%
Other Options
Opt. 0L2 Extra manual sets
Opt. 1CM Rackmount kit*
Opt. UK6 Commercial calibration
with test result data
E3600A-100 Test lead kit
Model Number
E3631A
E3632A E3633A E3634A
1 2 3
AC Input (47 Hz – 63 Hz) 100 Vac ±10% (Opt 0E9)/115 Vac ±10% (Std)/230 Vac ±10% (0E3)
Dimensions 213 x mm W x 133 mm H x 348 mm D
(8.4 x 5.2 x 13.7 in)
Weight 8.2 kg (18 lbs) net, 11 kg (24 lbs) shipping 9.5 kg (21 lbs) net, 12 kg (26 lbs) shipping
Warranty Three years for E363xA series power supplies
Three months for standard shipped accessories
Product Regulation Certified to CSA 22.2 No. 231 (for E3631A), No. 1010.1 (for E3632A/33A/34A);
conforms to IEC 1010-1; carries CE marks; complies with CISPR-11, Group 1, Class A
Rackmount Kits*
Agilent E3631A/32A/33A/34A
To rackmount two instruments side-
by-side
Lock-link Kit (P/N 5061-9694)
Flange Kit (P/N 5063-9214)
To rackmount one or two instruments
in a sliding support shelf
Support Shelf (P/N 5063-9256)
Slide Kit (P/N 1494-0015) required
for support shelf
* Rackmounting with 1CM or
lock-link/flange kit requires
Agilent or customer support rails
Agilent Support Rails-E3663AC
