XDS Series 5–15 kW
Controls and Indicator
Controls
Voltage setting: Digitally encoded rotary knob
Current setting: Digitally encoded rotary knob
Measurement select: Push button
Output on/off: Push button
Power on/off: Toggle switch
Indicators
Display: Dual 7 segment large LED
LED’s for: Output on/off, cc mode, cv mode,
remote, measurements.
Remote Control
A standard RS232C and analog RPV (0-10 VDC)
are included with all XDS Series DC Power
Supplies. An optional GPIB/IEEE-488 input is
available as well.
RS232C - Standard
9 pin D-shell connector, 19200 baud, SCPI syntax
RPV Input - Standard
Input: 0-10 VDC for 0-100% range
Connector: 15 pin D-sub.
Remote Inhibit - Standard
Programmable for default high or low
-IF Option
IEEE-488 Interface
IEEE-488 (GPIB) talker listener.
Subset: AH1, L3, RL2, SH1, T8
IEEE-488.2 SCPI syntax
Environmental
Temperature Coefficient
Voltage set point: 0.02%/°C of V Range
Current set point: 0.03%/°C of I Range
Ambient Temperature
Operating: 0° to 40° C / 32° to 104° F
Storage: -40° to 75° C / -40° to 167° F
Humidity
Operating: 0 to 80% RH, non condensing
Cooling
Forced air, side and top intake, rear exhaust
Mechanical
Dimensions
Height: 5.25” / 133.35 mm
Width: 19” / 482.6 mm
Depth: 22.19” / 563.3 mm excl. bus
bars and cover
24.74” / 628.4 mm incl. bus
bars and cover
Weight 15 KW 10 KW 5KW
Net:
90 lbs. 70 lbs. 50 lbs.
41 Kg 32 Kg 23 Kg
Shipping (approx.):
125 lbs. 105 lbs. 85 lbs.
57 Kg 48 Kg 39 Kg
Rack Mounting: Unit must be supported by shelf
or brackets when mounted in 19” cabinet. No
provisions for rack slides are made on instrument.
Ordering Information
Model
All XDS Series model numbers specify voltage and
current range.
XDS VVV-CCC-LLL-XX-XXXXX
VVV = Voltage
CCC = Current
LLL = Input Line Voltage
XX = Options
XXXXX = Configuration
Refer to table shown for model numbers and
configurations.
Includes
• User manual and programming manual
on CD ROM.
• Windows GUI software on CD ROM.
• RS-232C serial cable
Options
-IF GPIB / IEEE-488 interface
programming option.
-400 400 ±10% volt line to line AC input
-480 480 ±10% volt line to line AC input
Optional Configurations
-AUX
Auxilliary control.
-RPV5 Remote voltage programming, 0-5V
-RPV10 Remote voltage programming, 0-10V
-RPC5 Remote current programming, 0-5V
-RPC10 Remote current programming, 0-10V
Ordering Examples:
Model Description
XDS 50-100-208 Output voltage range is 50 Vdc,
maximum current is 100 Adc, line input is 208
V line to line, three phase. Includes standard
RS232C and analog interfaces.
XDS 80-187-400-IF Output voltage range is 80
Vdc, maximum current is 187 Adc, line input is
400 V line to line, three phase. Includes optional
IEEE/RS232 and analog interfaces.
