7

Measurements (continued)

54810A, 54815A, 54820A and 54825A

54835A and 54845A

Mask Testing

Allows pass/fail testing to user-defined or Agilent-supplied waveform templates. Up to 8 regions of polygons
allowed. Mask inversion inverts mask around baseline. Test modes include test forever, test to specified time or
event limit, and stop on failure. Auto-mask allows user to define tolerance range in time/voltage or percentage
and create a mask template from a captured waveform. Masks can be automatically aligned with the incoming
signal. All masks can be manually scaled via controls or the mouse.

Communications Mask Option

Option 100 provides a set of ITU G.703 and ANSI T1.102 industry standard masks for compliance testing.
For a complete list of the masks provided, request Agilent Communications Mask Testing Option 100
technical data sheet (see page 8)

Measurement Toolbar

16 Drag and Drop automatic measurement icons.

QuickMeas+

Allows user to configure a button below the display for the following functions:
QuickMeas: activates 4 preselected automatic measurements. QuickPrint: prints out screen.

QuickScreen: saves screen image to file; multiple button pushes increments filename suffix (e.g. Data01, Data02, etc.).

QuickWaveform: saves waveform data to a file on the disk drive; multiple button pushes increments filename suffix.
QuickSetup: loads in a specific instrument setup file

Markers Modes

Manual Markers, Track Waveform Data, Track Measurements

Waveform Math

4 functions f1-f4. Select from Add, Subtract, Multiply, Divide, Invert, Magnify, Vs, Min, Max, Integrate,
Differentiate, FFT Magnitude. Any of the Waveform Math functions (e.g., FFT) can be averaged.

FFT
Frequency Range

5

54820A/54825A: dc to 1 GHz (Sample rate/2)

54835A: 2 channel mode – dc to 2 GHz

54810A/54815A: dc to 500 MHz (Sample rate/2)

4 channel mode – dc to 1 GHz

54845A: 2 channel mode – dc to 4 GHz

4 channel mode – dc to 2 GHz

Frequency Accuracy

(1/2 frequency resolution)+(5x10

-5

)(signal frequency) (1/2 frequency resolution)+(7x10

-5

)(signal frequency)

Amplitude Display

Power in dBm

Signal-to-noise ratio

70 dB at 32K memory depth. Noise floor varies with memory depth and with averaging.

Window Modes

Hanning, Flattop, Rectangular

Computer System/Storage
CPU

AMD K6-2™ 400 MHz microprocessor

Disk Drives

3.2 GByte internal hard drive. Storage capacity is limited only by disk space. 3.5" 120 MB LS-120 SuperDisk
floppy drive (reads/writes to std. 3.5” floppies). Store and recall setups, waveforms, and store screen
images to both the hard drive and the floppy drive.

File types: Waveforms

Internal Y values; X and Y values in ASCII or Microsoft Excel formats

Images

BMP, PCX, TIF, GIF, EPS or PS formats

Mouse

Standard mouse supplied. Supports any Microsoft

®

mouse-compatible pointing device, serial or PS/2

Waveform Memories

4 nonvolatile waveform memories

I/O
LAN

Enables data/setup file transfers and use of network printers; supports Microsoft Networking;
10/100 MBPS operation that complies with IEEE 802.3 Ethernet and ISO/IEC 8802-3 Ethernet standards;
TCP/IP protocol and RJ-45 connector.

HP-IB

Fully programmable, complies with IEEE 488.2

RS-232 (serial)

2 ports: COM1, COM2. Printer and pointing device support

Centronics

Printer support

Printers

Full support of HP DeskJet and LaserJet printers. Visit the Infiniium website at
http://www.agilent.com/find/infiniium

PS/2 port

For PS/2 mouse

Keyboard port

Standard keyboard for file naming and waveform annotation, scope control

Video Output

15 pin VGA, full color

Auxiliary Output

DC (±2.5v); square wave (715 Hz [±5%], 350 mVpp [±5%]); trigger output (350 mVpp [±5%], frequency
varies with occurance of trigger)

General Characteristics
Temperature

Operating:

0°C to +50°C

10°C to +40°C

Nonoperating:

-40°C to 70°C

Humidity

Operating:

Up to 95% relative humidity (noncondensing) at +40°C

Nonoperating:

Up to 90% relative humidity at +65°C

Performance Characteristics

* Denotes Warranted Specifications, all others are typical. Specifications are valid after a 30-minute warm-up period, and ±10°C (models 54810A/15A/20A/25A) or
±5°C (models 54835A/45A) from firmware calibration temperature.
