Performance Characteristics
* Denotes Warranted Specifications, all others are typical. Specifications are valid after a 30-minute warm-up period, and ±10°C (models 54810A/15A/20A/25A) or
±5°C (models 54835A/45A) from firmware calibration temperature.
54810A, 54815A, 54820A and 54825A
54835A and 54845A
Offset Range
Vertical Sensitivity Available Offset
Vertical Sensitivity Available Offset
1 mV to 49 mV/div ± 2 V
1M
Ω
: 2 mV/div to 100 mV/div ± 4 V
> 50 mV to 249 mV/div ± 10 V
>100 mV/div to 2 V/div ± 40 V
> 250 mV to 1.24 V/div ± 50 V
50
Ω
: all > ± 12 div
1.25 V to 5V/div ± 250 V
Dynamic Range
± 12 div from center screen
±8 div from center screen
Full resolution channel scales
All volts/division settings >= 7 mV/div
10, 20, 50, 100, 200, 500, 1000 mV/div
(plus 2000 mV/div in 1 M
Ω
)
dc Gain Accuracy*
2,3
± 1.25% of full scale at full resolution channel scale ± 1% of full scale at full resolution channel scale
Resolution
2
Real Time
8 bits (0.4% of full scale), 12 bits or greater with sufficient averaging
Equivalent Time
8 bits (0.4% of full scale), 12 bits or greater with sufficient averaging
Offset Accuracy*
2
± (1.25% of channel offset + 2% of full scale) ± (1% of channel offset + 1% of full scale)
at full resolution channel scale
at full resolution channel scale
dc Voltage Measurement Accuracy*
2,3
Dual Cursor
±[(dc gain accuracy)+(resolution)]
Single Cursor
±[(dc gain accuracy)+(offset accuracy)+(resolution/2)]
Example (Single cursor accuracy,
Accuracy = ±[1.25%(80mV) + (1.25%(0)+2%(80 mV)) + Accuracy = ±[1%(80mV) + (1%(0 V)+1%(80 mV)) +
70 mV signal,10 mV/div, 0 offset)
(.4%/2)(80 mV)] = ±2.8 mV
(.4%/2)(80 mV)] = ±1.76 mV
AutoProbe Interface
AutoProbe is an intelligent communication and power link between compatible probes and Infiniium scopes.
AutoProbe completely configures the scope for the attached probe. For instance, it identifies the probe type
and sets up the proper input impedance, attenuation ratio, probe power and offset range, as needed.
Horizontal
Main Time Base Range
500 ps/div to 20 s/div
100 ps/div to 20 s/div
Horizontal Position Range (pre trigger)
0 to -1 s or one full screen width, whichever is larger
Horizontal Position Range (post trigger)
0 to 1 s or one full screen width, whichever is larger
Delayed Sweep Range
1 ps/div to current main time base setting 1 ps/div to current main time base setting
Delayed Sweep Delay Range
Within main time base acquisition record
Resolution
10 ps
2 ps
Timebase Accuracy
50 ppm (.005%)
70 ppm (.007%)
Delta-t Accuracy*
Real Time mode4
±[(.005%)(delta-t) + (0.2)(sample period)]
±[(.007%)(delta-t)+(0.2)(sample period)]
Equivalent Time mode (
≥
16 avgs.)
±[(.005%)(delta-t) + (full scale/(2*memory depth)) + 60ps] ±[(.007%)(delta-t)+(full scale/(2*memory depth))+ 30ps]
Peak Detect mode
±[(.005%)(delta-t)+(1 sample period)]
n/a
Example (Equivalent Time mode (
≥
16 Accuracy = ±[(.005%)(9 ns)+((10 ns)/(2*32,768))+ 60ps] = Accuracy = ±[(.007%)(9 ns)+((10 ns)/(2*65,536))+ 30ps] =
avgs.), 9 ns signal, 1 ns/div, 1 channel) ±[(450 x 10
-15
)+(152 x 10
-15
)+(60 x 10
-12
] = 61 ps ±[(630 x 10
-15
)+(76 x 10
-15
)+(30 x 10
-12
] = 31 ps
Jitter, RMS
n/a
8 ps ± .005% (delay setting)
Trigger
Sensitivity*
2
Internal (normal)
dc to 100 MHz: 0.5 div
0.5 div
100 MHz to 500 MHz: 1.0 div
1.0 div
500 MHz to 1 GHz: N/A
1.5 div
Internal (noise reject) dc to 100 MHz: 1.0 div
N/A
100 MHz to 500 MHz: 1.5 div
External (54810/20A)
dc to 100 MHz: 0.0225 x (signal range)
N/A
100 MHz to 500 MHz: 0.045 x (signal range)
Auxiliary (54815/25/35/45A)
dc to 500 MHz: 300 mVp-p
300 mVp-p
Maximum Input Voltage*
1 M
Ω
: ±250 V (dc + ac) [ac<10 kHz],
External (54810/20A)
CAT I, 50
Ω
: 5 Vrms, CAT I
n/a
Auxiliary (54815/25/45A)
2.5 k
Ω
: ±15 V, CAT I
2.5 k
Ω
: ±15 V, CAT I
Minimum Pulse Width
(internal, external)
1 ns at > 1.0 div
500 ps at > 1.0 div
Level Range
Internal
± 12 div from center screen
± 8 div from center screen
External (54810/20A)
± 1 V, ± 5 V, ± 25 V
n/a
Auxiliary (54815/25/45A)
± 5 V
± 5 V
