TECHNICAL DETAILS
GENERAL SPECIFICATION
TRIGGER CIRCUIT
Release of pulses Automatic, manual, external
Synchronization 0° - 360°, resolution 1°
OUTPUT
Direct Via HV-safety lab connectors
Coupling mode Line to line
Line(s) to ground (PE)
DUT supply
OCS 500N6F AC: 250V/16A; 50/60Hz
DC: 250V/10A
OCS 500N6F.1 AC: 250V/32A; 50/60Hz
DC: 250V/20A
OCS 500N6F.2 AC: 3x440V/16A; 50/60Hz
DC: 250V/10A
OCS 500N6F.3 AC: 3x440V/32A; 50/60Hz
DC: 250V/20A
CRO trigger 5V trigger signal for oscilloscope
MEASUREMENTS
Ring wave Peak voltage and peak current in LCD
TEST ROUTINES
Quick Start Immediate start; easy-to-use and
fast
Standard Test
routines As per IEC 61000-4-18
As per IEC 61000-4-12, Level 1 - 4
Manual Standard Test routine
As per ANSI/IEEE C62.41
As per IEC 61000-4-10, Level 1 - 5
User Test routines Change polarity after n pulses
Change coupling after n pulses
Change voltage after n pulses
Change phase angle after n pulses
GENERAL DATA
INTERFACE
Optical interface Opto link, 3 m cable
USB A connector
Parallel interface IEEE 488, addresses 1 - 30
GENERAL DATA
Dimensions,
weight 19"/9HU, approx. 32kg (1-phase)
19"/9HU, approx. 50kg (3-phase)
Supply voltage 115/230V +10/-15%
Fuses 2 x T2AT (230V); 2 x T4AT (115V)
OPTIONS
ACCESSORIES COUPLING NETWORK
CNV 504N5.1 Coupler for 4 signal/datalines for
damped oscillatory waves 100kHz
and 1MHz as per IEC 61000-4-18,
50V/4A
CNV 504N5.3 Coupler for 4 signal/datalines for
damped oscillatory waves 100kHz
and 1MHz as per IEC 61000-4-18,
250V/4A
CNV 508N4 Coupler for 4 pairs (8 wires) as per
IEC 60255-22-1, 250V/4A
CNV 508N4.1 Coupler for 4 pairs (8 wires) as per
IEC 60255-22-1, 250V/16A
HFK Capacitive coupling clamp as per
IEC 61000-4-4
MS 100N Magnetic Field coil for EN/IEC
61000-4-10 application
ACCESSORIES SOFTWARE, VERIFICATION
iec.control Remote control and documentation
software with library of standards
CA OCS F Kit Load resistor set for fast damped
oscillatory wave verification,
KW 0R1 load resistor 0.1ohm,
KW 1000 load resistor 1000ohm,
CA MC F Adapter to match KW 0R1
and KW 1000 to the supply output of
the OCS 500N6F
