DATA SHEET > OCS 500N6F series > 20130618

TECHNICAL DETAILS

OCS 500N6F MAIN-UNIT MODELS

OCS 500N6F

With built-in CDN
AC 250V / 16A
DC 250V / 10A

OCS 500N6F.1

With built-in CDN
AC 250V / 32A
DC 250V / 20A

OCS 500N6F.2

With built-in CDN
AC 3x440V / 16A
DC 250V / 10A

OCS 500N6F.3

With built-in CDN
AC 3x440V / 32A
DC 250V / 20A

FAST DAMPED OSCILLATORY
MODULE

FAST DAMPED OSCILLATORY WAVES AS PER IEC/EN
61000-4-18

Voltage (o.c.) at
HV output

450V - 4,400V ±10%

Rise time

5ns ±30%

Oscillation
frequencies

3MHz, 10MHz and 30MHz, ±10%

Decaying

Peak 5 to be > 50% of peak 1 value
Peak 10 to be < 50% of peak 1 value

Source impedance

50ohm ±20%

Polarity

Positive, negative

Repetition rate

Max. 5,000/s ±10%

Burst duration

50ms ±20%, at 3MHz
15ms ±20%, at 10MHz
5ms ±20%, at 30MHz

Burst period

300ms ±20%

Short-circuit
current

9A - 88A ±20%

Rise time current
waveform

< 330ns at 3MHz
< 100ns at 10MHz
< 33ns at 30MHz

Decaying (current)

Peak 5 to be > 25% of peak 1 value
Peak 10 to be < 25% of peak 1 value

SLOW DAMPED OSCILLATORY
MODULE (OPTION)

SLOW DAMPED OSCILLATORY WAVES AS PER IEC/EN
61000-4-18 (OPTION)

Voltage (o.c.) at
HV output

250V - 3,000V ± 10%

Voltage (o.c) at
line output

250V - 2,500V ± 10%

Rise time

75ns ± 20%

Oscillation
frequencies

100kHz and 1MHz ± 10%

Decaying

Peak 5 to be > 50% of peak 1 value
Peak 10 to be < 50% of peak 1 value

Source impedance

200ohm ± 20%

Polarity

Positive, negative

Repetition rate

Max. 50/s for 100kHz and
Max. 500/s for 1MHz

Burst duration

At least 2s

RINGWAVE MODULE (OPTION)

RINGWAVE AS PER IEC/EN 61000-4-12 AND ANSI/IEEE
C62.41 (OPTION)

Voltage (o.c.)

250V - 6,000V ± 10%

Rise time

0.5us ± 30%

Oscillation
frequency

100kHz ± 10%

Decaying

Ratio of peak 2 to peak 1: 0.4 - 1.1
Ratio of peak 3 to peak 2: 0.4 - 0.8
Ratio of peak 4 to peak 3: 0.4 - 0.8

Source impedance

12ohm and 30ohm ± 20%
200ohm for I/O lines (CNV 504N5)

Peak current (s.c.)

Max. 500A @ 12ohm or
Max. 200A @ 30ohm internally;
Max. 30A @ 200ohm, with
CNV 504N5

Rise time

< 1us

Oscillation
frequency

100kHz ± 10%

Polarity

Positive, negative

Repetition rate

1 to 60 transients per minute
