Micropulse module,

Pulse 1, 2 based on ISO 7637-2:2004

Micropulse module,

Pulses based on Jaso and Nissan

Test Level Output

Open circuit voltage

U = 20V – 600V

± 10% ( Peak voltage

and polarity acc. to the selected standard)

Repetition rate

0.2s – 99.0s

ISO Pulse 1 (12V)

Rise time tr (10 - 90%)

1µs + 0% // - 50%

Pulse duration td (10 - 10%)

2ms

± 10%

Internal resistor

10

Ω ± 10%

ISO Pulse 1 (24V)

Rise time tr (10 - 90%)

3µs + 0% // - 50%

Pulse duration td (10 - 10%)

1ms

± 10%

Internal resistor

50

Ω ± 10%

ISO Pulse 2 (12V/24V)

Rise time tr (10 - 90%)

1µs + 0% // - 50%

Pulse duration td (10 - 10%)

50µs

± 10%

Internal resistor

2

Ω ± 10%

As per ISO 7637-2 the following standards can be covered

SAE J1113

GM 3097

BMW

VW

Chrysler PF 9326

PSA

DC10614

Renault

FIAT

Mitsubishi

Ford ES-XW7T

Honda

Option Pulse Programming Mode

Rise time

1

µs to 10µs with steps of 1µs

Pulse duration

50

µs to 10,000us

Internal resitor

2

Ω-100Ω in steps of 5Ω, 200, 400 & 450Ω

Trigger

Automatic

Automatic release of the pulses

Manual

Manual release of a single pulse

External

External release of a single pulse

Battery supply switch

Selectable Off time, to = 0 – 10,000ms

Output

+/- output

Central DUT output

Coupling

To the battery +line

Decoupling

Via diode and battery supply switch

Test Routines

Quick Start

Immediate start; easy to use and fast

User Test Routines

1. Custom made test routines
2. Change voltage after n pulses by

∆V

Pulse selctor
Service

Service, setup, self test

Interface

Serial interface

RS 232, baud rate 1200 - 19200

Parallel interface

IEEE 488, address 1 - 30

CN interface

To control the internal CN and battery
switch

JASO D 001
Pulse A2 as per JASO D 001

Test voltage

+110V

Capacitor

C = 4.7µF

Pulse duration at

τ

τ(36,8%) = 2.5µs ± 30%

R1

0.6

Ω ± 10%

R2

0.4

Ω ± 10%

Polarity

Positive

Pulse B2 as per JASO D 001

Test voltage

-260V

Capacitor

C = 33µF

Pulse duration at

τ

τ(36,8%) = 2.0ms ± 20%

R1

60

Ω ± 10%

R2

80

Ω ± 10%

Polarity

Negative

Pulse D2 as per JASO D 001

Test voltage

+170V

Capacitor

C = 2.2µF

Pulse duration at

τ

τ(36,8%) = 2.5µs ± 30%

R1

1.2

Ω ± 10%

R2

0.9

Ω ± 10%

Polarity

Positive

Nissan NDS
Pulse B2 as per Nissan

Open circuit voltage

– 300V

± 10%

Capacitor

C = 33µF

R1

100

Ω ± 10%

R2

75

Ω ± 10%

Polarity

Negative

Pulse C8 as per Nissan

Open circuit voltage

±300V ± 10%

Capacitor

C = 1µF

R1

500

Ω ± 10%

R2

450

Ω ± 10%

Polarity

Positive and negative

Pulse C50 as per Nissan

Open circuit voltage

±300V ± 10%

Capacitor

C = 33µF

R1

30

Ω ± 10%

R2

200

Ω ± 10%

Polarity

Positive and negative

Pulse C300 as per Nissan

Open circuit voltage

- 300V

± 10%

Capacitor

C = 33µF

R1

100

Ω ± 10%

R2

75

Ω ± 10%

Polarity

Negative
