PARAMETRY TECHNICZNE
MICROPULSES AS PER
MANUFACTURER STANDARDS
JASO D-001, PULSE A2
Test voltage +110V
Capacitor C = 4.7uF
Pulse duration 2.5us ± 30% at tau(36.8%)
R1 0.6ohm ± 10%
R2 0.4ohm ± 10%
Polarity Positive
JASO D-001, PULSE B2
Test voltage -260V
Capacitor C = 33uF
Pulse duration 2.0ms ± 20% at tau(36,8%)
R1 60ohm ± 10%
R2 80ohm ± 10%
Polarity Negative
JASO D-001, PULSE D2
Test voltage +170V
Capacitor C = 2.2uF
Pulse duration 2.5us ± 30% at tau(36,8%)
R1 1.2ohm ± 10%
R2 0.9ohm ± 10%
Polarity Positive
NISSAN 28400 NDS 03, PULSE B2
Test voltage -300V ± 10%
Capacitor C = 33uF
R1 100ohm ± 10%
R2 75ohm ± 10%
Polarity Negative
NISSAN 28400 NDS 07, PULSE C8
Test voltage ±300V ± 10%
Capacitor C = 1uF
R1 500ohm ± 10%
R2 450ohm ± 10%
Polarity Positive and negative
MICROPULSES AS PER
MANUFACTURER STANDARDS
NISSAN 28400 NDS 07, PULSE C50
Test voltage ±300V ± 10%
Capacitor C = 33uF
R1 30ohm ± 10%
R2 200ohm ± 10%
Polarity Positive and negative
NISSAN 28400 NDS 07, PULSE C300
Test voltage -300V ± 10%
Capacitor C = 33uF
R1 100ohm ± 10%
R2 75ohm ± 10%
Polarity Negative
SAE J1455 | MUTUAL PULSE
Rise time 1us ± 20% (10% - 90%)
Pulse duration 15µs ± 20% at tau(36.8%)
Int. resistor 50ohm ± 10%
SAE J1455 | INDUCTIVE PULSE
Rise time 1us ± 20% (10 - 90%)
Pulse duration 1,000us ± 20% at tau(36.8%)
Int. resistor 20ohm ± 10%
FREESTYLE MODE MICROPULSES
PULSE PROGRAMMING MODE
Rise time 1us - 10us in steps of 1us
Pulse duration 50us - 10,000us
Int. resistor 2ohm - 100ohm in steps of 5ohm;
200ohm, 400ohm and 450ohm
