R3010 R3030
Frequency Range 9kHz÷30MHz 9kHz÷300MHz
Frequency Setting 1Hz (9kHz÷30MHz) 1Hz (9kHz÷300MHz)
Internal Reference Frequency
Aging per Year 2 x 10 -6
Temperature Drift 15 x 10 -5 (+10 °C to +40 °C)
External Reference Frequency 10 MHz
Frequency Display Local And Remote (manual mode) Numeric Display
Resolution 1Hz
Frequency Display Remote (sweep mode) Graphic Display on PC SW
Resolution Frequency Step (zoom function)
Measurement Time (manual mode) 2ms to 90min
1ms (< 60sec)
Resolution
1sec (> 60sec)
Measurement Time (sweep mode) 2ms to 60s
Resolution 1ms
200Hz (-6dB Bandwidth)
9kHz (-6dB Bandwidth) Digital EMI Filters BW
120kHz (-6dB Bandwidth)
15kHz
Hardware Filters BW
1MHz
9 kHz to 150kHz 9 kHz to 150kHz
150 kHz to 2MHz 150 kHz to 2MHz
2MHz to 6MHz 2MHz to 6MHz
6MHz to 15MHz 6MHz to 15MHz
15MHz to 30MHz 15MHz to 30MHz
30 MHz to 60 MHz
60 MHz to 140 MHz
Fixed & Tunable Preselection Filters
140 MHz to 300 MHz
Maximum Input Level
DC Voltage 50V (AC-coupled)
CW RF Power +20dBm
Pulse Spectral Density +97dBµV/MHz
Immunity to Interference
Image Frequency > 60dB
Intermediate Frequency > 70dB
RF Shielding 3V/m (50 Ω termination)
Noise Floor IF 200 Hz IF 9kHz IF 120kHz (R3030)
Peak < -10dBµV < 10dBµV < 10dBµV
Quasi Peak < -15dBuV < 5dBuV < 5dBuV
CISPR Average < -20dBuV < 0dBuV < 5dBuV
RMS < -20dBuV < 0dBuV < 5dBuV
CISPR RMS < -20dBuV < 0dBuV < 5dBuV
FRONT PANEL with Knob
Display 3,5 Inch TFT with Touch Panel
Features Virtual Keyboard
Level Display (digital) Numeric (resolution 0,01dB)
Level Display (analog) Bargraph
Detectors Peak, Quasi-Peak, CISPR Average, RMS, CISPR RMS
Number of Contemporary Detectors 3
Display Units dBµV, dBm, dBµV/m, dBµA/m, dBA/m, dBµA, dBpW
RF Input Impedance 50 Ω
N female (RF 9kHz to 30MHz) N female (RF 9kHz to 30MHz)
RF Input Connector(s)
N female (RF 30MHz to 300MHz)
2,0 to 1,0 (attenuation 0dB)
RF Input VSWR
1,2 to 1,0 (attenuation ≥ 10dB)
RF Input Attenuator 0dB to 50dB in 10dB steps
IF Output Impedance 50 Ω
IF Output Connector N female
10,7 MHz 10,7MHz (< 30MHz)
IF Frequency
18MHz (> 300MHz)
Tracking Generator +50÷+95dBµV +50÷+95dBµV (9kHz÷150MHz)
Interface Ethernet 10/100 MB (TCP Port: 1893)
Pentium Dual Core Processor
Above 1GB RAM (min)
Ethernet 10/100 MB Network Board
PC Requirement
WIN XP, WIN VISTA, WIN 7 OS
Power Supply 230Vac ± 10% 50-60Hz
Power Consumption 50VA
Operating Temperature 0° to 45°C
Storage Temperature -20° to 70°C
Size (W x H x D) 450x135x436mm.
Weight 14kg 15kg
AFJ Instruments
Via Corno di Cavento 5
20148 Milan – Italy
Phone +39 02 91434850
[email protected]
www.afj-instruments.com
Version 01 December 2011. Subject to change without notice.
