OUTPUT OPTIONS
POWER PACKS POWER PACK FEATURES
THE ITIG II IS AVAILABLE WITH
4KV, 6KV AND 12KV MAXIMUM
OUTPUTS.
The Power Pack is used to test large, high
voltage rotating machines and transformers.
Surge tests are load dependent and
influenced by operating voltage, power,
speed, frame size and coil type. √ 24kV and 30kV Power Packs are portable
and have the same rugged case as the iTIG
II.
√ The iTIG II captures, displays, and stores
the test data from the Power Pack.
LANGUAGES
The iTIG II and TRPro report software are
available in multiple languages.
Electrom Instruments • +1 720-491-3580 • [email protected] • www.electrominst.com
WINDOWS OPERATING SYSTEM
AND REPORT SOFTWARE
Surge Fail
IR Fail
Step Test Tripout
Ohms Balance Fail
Off-line Equip. Rating
On-line Equip. Rating NO
NO
NO
NO
PASS
PASS
PASS / FAIL RESULTS
▶ Test Report Pro or TRPro runs
on PCs and works with models
B to D
▶ Data is easily transferred back
and forth between the iTIG II
and a PC or server. It can be
done with one click using a
memory stick or through an
Ethernet connection.
▶ Reports can also be printed
directly from the iTIG II.
