PROTOCOL
DPMR (OPTiOnAl)
RF sIGNAL GENERATOR
RF RECEIVER
dPMR MEAsUREMENTs
Decode Color Code, Call ID, Unit ID
Simulation Color Code, Call ID
symbol Deviation
Range 1500 Hz to 2350 Hz
Resolution 0.1 Hz
Accuracy ±10 Hz (1745 to 2140 Hz)
symbol Clock Error
Range ±1000 mHz
Resolution 0.01 mHz
Accuracy 1 ppm (-48 to +48 mHz)
Frequency Error
Range ±4000 Hz
Resolution 0.01 Hz
Accuracy Frequency Standard ± 1 count
Magnitude Error
Range 0 to 5%
Resolution 0.01%
Accuracy <10% of reading (0 to 2%)
UUT TX/RX bit Error
Rate
Range 0 to 20%
Resolution 0.1 %
signal Power/slot
Power
Range T/R port: -60 to +51 dBm
ANT port: -100 to +10 dBm
Resolution 0.1 dB
Accuracy ±1 dB (typically better than ±0.6 dB)
FREQUENCY
Range 10 MHz to 1.05 GHz (Standard)
(Usable from 100 kHz)
10 MHz to 2.7 GHz (392XOPT058)
(Usable from 100 kHz)
Resolution 1 Hz
Accuracy Frequency standard ±1 count
OUTPUT LEVEL
Range T/R Port: -138.0 dBm to -30.0 dBm
for 4FSK
Gen Port: -130.0 dBm to +10.0
dBm for 4FSK
Resolution 0.1 dB
Accuracy 1.0 dB for levels >-110 dBm (typical
better than 0.6 dB)
1.5 dB for levels ≤-110 (typical
better than 1.0 dB)
Modulation 4FSK
Test Patterns STD 511 (0.153)
Frequency Range 10 MHz to 1.05 GHz (standard)
(Usable from 100 kHz)
10 MHz to 2.7 GHz
(392XOPT058) (Usable from
100 kHz)
Resolution 1 Hz
Level Range T/R Port: -10 to +50 dBm
ANT Port: -60.0 to +10 dBm
(with preamp -63)
FsK ERROR METER
Range 0 to 20%
Resolution 0.01%
Accuracy <5.0% of reading (2.5 to 10%)
sYMbOL DEVIATION METER
Range 875 Hz to 1225 Hz
Resolution 0.1 Hz
Accuracy ±10 Hz (945 to 1155 Hz)
sYMbOL CLOCK ERROR METER
Range ±1000 mHz
Resolution 0.01 mHz
Accuracy 1 ppm (-24 mHz to +24 mHz)
FREQUENCY ERROR
Range ±4000 Hz
Resolution 0.01 Hz
Accuracy Frequency Standard ±1 count
