1. Installation
21
033-082-C0-002 Rev. B
1.5
Battery Installation, continued
Fig 1-7 UPE-M3 / BSM-3 Battery Pack
Co-Terminate
with existing wire
Attach RTS here
Fuse
Co-Terminate
with existing wire
UPE-M3
Battery Pack
BSM-3
Battery Pack
Front of
Enclosure
Existing wiring not shown
for clarity
Co-Terminate
with existing wire
Attach RTS here
Fuse
Co-Terminate
with existing wire
UPE-M3
Battery Pack
BSM-3
Battery Pack
Front of
Enclosure
Existing wiring not shown
for clarity
