1. Installation
10
033-082-C0-002 Rev. B
Overview
The Battery Side Module was designed to allow the customer to add
additional batteries in the field for additional standby/run time. The
BSM-3 was designed for use with the UPE-M3 enclosure only.
WARNING: DO NOT install a BSM-3 on both sides of the UPE-M3,
or install a second power supply in the UPE-M3, to do
so will void your warranty and result in thermal
damage to the power supply and battery packs.
Upon receipt, the enclosure should be unpacked and inspected for
shipping damage. The following items should be enclosed:
1. BSM-3 Enclosure and door, with two
sets of keys.
2. 6 aluminum rivets and 2 sets of #10 nuts and
bolts for mounting the BSM-3.
3. Battery cable conduit, consisting of a chase
nipple, lock washer and bushing.
4. Self adhesive insulation pads, and weather stripping.
5. Battery Cable Kit (Alpha P/N 874-479-22).
Tools and Materials Needed:
Center Punch or Permanent Marker
Tape measure
Electric or pneumatic drill
No. 7 drill bit (.203”)
#2 Phillips screw driver
Hand operated rivet gun with .188” nosepiece
Drill-stop collar for No. 7 drill bit
Hole saw or hydraulic punch for 1.375” hole
Wet-dry vacuum
Utility knife
1” Chase nipple (supplied)
1” locknut (supplied)
1” plastic bushing (supplied)
Enclosure Cooling Fan Kit (if not previously installed)
6 aluminum rivets (supplied)
2 #10-32 x 3/4” pan-head screws (supplied)
2 #10-32 Nuts (supplied)
4 #10 Paint-Break washers (supplied)
Procedure:
NOTE: Metal shavings will enter the UPE-M3 enclosure during this
procedure. Before proceeding, verify that the power supply, CB
box, Service Entrance and batteries are disconnected and
protected.
1.1.1. Enclosure Preparation
1.1 BSM Installation
