Ab c – Alpha Technologies BSM-3 Battery Side Module Enclosure User Manual
Page 15
1. Installation
15
033-082-C0-002 Rev. B
Enclosure
Door
Mounting
Stud
Magnet
(side View)
Lock
Washer
#6-32
Nut
Fig 1-3 Tamper Switch Replacement / Installation
A
B
C
Switch
(side View)
Door Frame
or Shelf
Pre-Drilled
Hole
Sheet Metal
Screw
Washer
Lock
BSM-3 Tamper
Switch
UPE-M3
Tamper Switch
'TMPR'
connection
Route through
conduit
1.2
Dual Tamper Switch Option, continued
1.2.1.
Tamper Switch Installation, continued
