Alpha Technologies BSM-3 Battery Side Module Enclosure User Manual
Page 16
1. Installation
16
033-082-C0-002 Rev. B
1.3
Enclosure Cooling Fan
Tools and Materials Needed:
3/8” Nut-driver or open end wrench
UPEM Fan Kit (Alpha P/N 744-797-24)
Procedure:
CAUTION:
Due to restricted air flow, an enclosure cooling fan
MUST be installed in the UPE-M3 enclosure when
using a Battery Side Module.
Refer to the UPEM Series installation manual (P/N 031-145-C0) for detailed
instructions on installing the fan kit.
Enclosure
Cooling Fan
SPI
1.3.1.
Cooling Fan
Fig 1-4 Fan Kit
