5. Alpha Part Numbers

40

031-103-B0-003 Rev. C

© 2002

TM

Part Number:

PCD 3-3: 641-072-10 (Reinforced concrete)
PCC 3-3: 641-069-10 (Polymer concrete)

0.000

3.00 RE F.

+3 .0

-0 .0

0.25

+.25

-.125

REF.

2

1

1

4" diameter opening (2 plcs.)

5" x 8" opening (6 plcs.)

2

5.2

Pre-Cast Concrete Pads,

continued

Figure 5-2; Double-Wide Pad, for CE8/9 or PN 3/4
