3. Installation
20
031-103-B0-003 Rev. C © 2002 TM
3.3.3 Sample Input Power Panels, continued
Neutral
Main
Disconnect
Line 1
Line 2
15A
15A
15A
50A
BBX-100A-8POS
IPP-240-2
120V/15A 240V/15A 240V/15A
GFCI
NO Main Bonding Jumper
G
N
Service and
Distribution Load
From
Feeder
Supply
Secondary Service:
1) Main Bonding Jumper is NOT Installed.
2) Grounding Electrode Conductor is NOT Installed.
3) Lightning Protection is part of feeder supply.
Equipment
Grounding
Conductor
Neutral
Main
Disconnect
Line 1
Line 2
20A
20A
15A 50A
BBX-100A-8POS
IPP-120-2
120V/15A
GFCI
NO Main Bonding Jumper
G
N
Service and
Distribution
Load
From
Feeder
Supply
Secondary Service:
1) Main Bonding Jumper is NOT Installed.
2) Grounding Electrode Conductor is NOT Installed.
3) Lightning Protection is part of feeder supply.
Equipment
Grounding
Conductor
120V/20A 120V/20A
Figure 3-6; Schematic: Secondary Service BBX-100A-8POS with IPP-120-2
Figure 3-7; Schematic: Secondary Service BBX-100A-8POS with IPP-240-2
