Alpha Technologies AlphaGen PN-6x-T 7.5kW 48Vdc User Manual
Page 20

20
042-288-B0-001, Rev. A2
Engine Specifications, CE-3x2 5K-T
Manufacturer:
Kohler
Make/model:
CV14
Cycle:
4
Compression Ratio:
8:5:1
Displacement, cu. in. (cc):
24.3 (398)
Rated Horsepower:
(using natural gas fuel)
10.5
Engine Speed (rpm):
2800-3600
Bore, in. (mm):
3.43 (87)
Stroke, in. (mm):
2.64 (67)
Valve Train:
Overhead valve
Valve Material:
Intake
Exhaust
Steel
Stellite
®
face
Number of Cylinders:
1
Cylinder Block Material:
Aluminum with cast iron liners
Cylinder Head Material:
Aluminum
Piston Rings: number/type:
2 compression, 1 oil
Crankshaft Material:
Heat treated, ductile iron casting
Bearings:
Number
Type
2
Replaceable sleeve
Governor:
Electronic
Starter Motor:
Electric, solenoid shift
Lubrication System:
Full pressure
Oil Capacity:
(with filter and cooler), qt. (L)
2.1 (2.0)
Oil Type: summer/winter:
Synthetic 5W-30
Oil Pressure, psi (kPa):
25-35 (172-241)
Low Oil Pressure, psi (kPa):
2-5 (13.8-34.5)
Fuel Type:
Natural gas or propane
Fuel Pressure, kPA (in. water):
7-11 (1.7-2.7)
Battery Voltage:
12Vdc
Battery Ground:
Negative
Battery Recommendation (min.):
425 CCA @ 0ºF ( -18ºC)
Spark Plug Type:
Kohler P/N 24 132 03
Spark Plug Gap, in. (mm):
0.75 (0.030)
Spark Plug Tightening Torque, ft.
lb (Nm):
18-22 (24.4-29.8)
Ignition System:
Battery/Coil
Cooling System:
Integrated air cooled
High Engine Temperature, ºF (ºC): 305 (152)
1.0
System Overview, continued
1.5
Specifications, continued
48Vdc Generator Set Specification
Manufacturer:
Kohler
Dimensions (in/mm): 24"L x 26"W x 44"H
546 x 508 x 554
Weight (lb/kg):
395/179
Rated* kW:
5kW
Rated Voltage:
(after rectifier)
52 ± 0.5Vdc @ no load
Rated Amps:
96 @ 52Vdc
Stator Resistance:
(ohms):
0.024
Stator Type:
3-phase, 3-lead,
ungrounded
Excitation Method:
Permanent magnet,
brushless
Coupling Type:
Direct-to-Engine
Insulation (stator):
Class 155,
epoxy varnish,
vacuum-impregnated
Winding Material:
Copper
* Derate approximately 4% per 1000 ft (300m)
over 500 ft (153m) above sea level. Derate 1%
for each 10ºF (5.5ºC) increase in temperature
above 77ºF (25ºC).
