18
CONTROL & FEATURES
Output Indicator
Overload Indicator
OUTPUT INDICATOR
(GREEN)
OVERLOAD INDICATOR
(RED)
The output indicator (green) is illuminated when the generator is
operating normally. It indicates that the generator is producing
electrical power at the DC output coupler.
The overload indicator (red) will go steady ON if the generator is
overloaded, the converter becomes overheated or there is a short
circuit in the connected UPS battery string. The overload indicator
(red) will stay ON, and after about five seconds, current to the
connected UPS and the output indicator (green) will go OFF. When the
UPS battery voltage is too low or too high, the overload indicator (red)
will flash.
