COMPONENT & CONTROL LOCATIONS
CONTROLS & FEATURES
ENGINE SWITCH
CHOKE KNOB
FUEL VALVE LEVER
OUTPUT
INDICATOR
OVERLOAD
INDICATOR
OUTPUT SWITCH
GROUND
TERMINAL
DC OUTPUT
COUPLER
VOLTMETER
OIL ALERT
INDICATOR
Use the illustrations on these pages to locate and identify the most
frequently used controls.
