10.1 Definitions and Settings, continued
Parameter OID Description Access Type Value
GENERAL CONTROLS
atiMgmtSysTamperPolarity 1.3.6.1.4.1.926.1.3.2.6.1.0 Determines when tamper is active Read/Write Integer 1=doorOpenWhenContactOpen
2=doorOpenWhenContactClosed
(default)
atiMgmtSysAlphaBusSize 1.3.6.1.4.1.926.1.3.2.6.2.0 Internal microprocessor communications bus size.
Alpha XM2 series power supplies use 9 bit. Alpha
GMX and VMX series supplies use 8 bit
Read/Write Integer 1=9 Bit (Default)
2=8 Bit
atiMgmtSysGnrlInfoConfigs 1.3.6.1.4.1.926.1.3.2.7.1 Object Identifier
atiMgmtSysGnrlInfoConfigsMain 1.3.6.1.4.1.926.1.3.2.7.1.1.0 An ASCII string programmed into the main board
non-volatile memory.
Read Only Octet String Product number, configuration
number serial number, etc.
atiMgmtSysGnrlInfoConfigsDaughter 1.3.6.1.4.1.926.1.3.2.7.1.2.0 An ASCII string programmed into the C/D battery
circuitry (DSM3x only).
Read Only Octet String Product number, configuration
number serial number, etc.
atiMgmtSysGnrlInfoConfigsBase 1.3.6.1.4.1.926.1.3.2.7.1.3.0 An ASCII string describing the base configuration
of the device.
Read Only Octet String i.e. DSM3, DSM3x, DPM, etc.
ENVIRONMENTAL I/O CONTROLLER
atiMgmtSysIo 1.3.6.1.4.1.926.1.3.2.8 Object Identifier
atiMgmtSysIoSelect 1.3.6.1.4.1.926.1.3.2.8.1 Indicates what function the IO pins are being
used for
Read/Write Integer 1 = Generic
2 = lapOnly
3 = heaterControlOnly
4 = generatorOnly
5 = heaterControlAndLap
6 = generatorAndLap
atiMgmtSysIoLAPState 1.3.6.1.4.1.926.1.3.2.8.2 Current state of the LAP device Read Only Integer 1: notInstalled(1)
2: ok(2)
3: acNotPresent(3)
4: lapBlown(4)
5: lapFail(5)
atiMgmtSysIoGenState 1.3.6.1.4.1.926.1.3.2.8.3 State of the DC Emergency Generator when
sense lines are used
Read Only Integer 1: notInstalled(1)
2: genOff(2)
3: genRunning(3)
4: genNotDetected(4)
5: error(5)
atiMgmtSysIoPinCtrl 1.3.6.1.4.1.926.1.3.2.8.20 Status of the ENV connector Output Pin (Pin 3) Read Only Integer 1 = Contact Open
2 = Contact Closed
atiMgmtSysIoPinIn4 1.3.6.1.4.1.926.1.3.2.8.21 Status of the ENV connector Input Pin#4 Read Only Integer 1 = Contact Open
2 = Contact Closed
atiMgmtSysIoPinIn5 1.3.6.1.4.1.926.1.3.2.8.22 Status of the ENV connector Input Pin#5 Read Only Integer 1 = Contact Open
2 = Contact Closed
atiMgmtSysIoPinIn6 1.3.6.1.4.1.926.1.3.2.8.23 Status of the ENV connector Input Pin#6 Read Only Integer 1 = Contact Open
2 = Contact Closed
PLATFORMS
atiProductPlatforms
1.3.6.1.4.1.926.1.4 Object Identifier
atiBroadbandUPS 1.3.6.1.4.1.926.1.4.1 Object Identifier
atiBBSysView 1.3.6.1.4.1.926.1.4.1.1 Object Identifier
atiBBSysViewSelects 1.3.6.1.4.1.926.1.4.1.1.1 Object Identifier
atiBBSysViewSelfTestControl 1.3.6.1.4.1.926.1.4.1.1.1.1.0 Starts/Stops a system self-test. Read/Write Integer 1=Stop
2=Start
atiBBSysViewSelfTestInhibit 1.3.6.1.4.1.926.1.4.1.1.1.2.0 System self-test is prevented. On reset, the DSM
gets this value from the master XM2 (in a system
with more than one power supply).
Read/Write Integer 1=Normal (Default)
2=Inhibited
atiBBSysViewSystemControlMgr 1.3.6.1.4.1.926.1.4.1.1.1.3.0 If the System Control Manager is running, the
Small System Controller/Administrator (SSC or
SSA) is running and there is coordination between
the power supplies for charging, testing, etc. The
value of this item is stored in non-volatile memory.
Read/Write Integer 1=Running
2=Disabled
