c 2004 ARGUS TECHNOLOGIES
CAN TERMINATED
JUMPER SETTING FOR P1
CAN UNTERMINATED
#6-32 SCREWS
L2/N
TB2 FEEDS RECTIFIERS 2, 4, 6
TB1
TYPICAL AC INPUT TERMINAL BLOCK
(TB1 SHOWN)
TB1 FEEDS RECTIFIERS 1, 3, 5
L1
P1
1. GND
2. CAN H
3. NOT CONNECTED
4. CAN L
5. NOT CONNECTED
6. NOT CONNECTED
DIMENSIONS ARE IN INCHES WITH METRIC (mm) IN BRACKETS: INCHES [mm]
SIZE DWG NO. TYPE
B
SHEET
TITLE
ISSUE
DATE
OF
SCALE
FOR MANUFACTURING WITHOUT ITS WRITTEN CONSENT.
ARGUS TECHNOLOGIES AND SHALL NOT BE COPIED OR USED
THESE DESIGNS AND SPECIFICATIONS ARE THE PROPERTY OF
REV 030-707-08 C D2
48-1kW CXRC 19" FLUSH MNT
2 4
CUSTOMER CONNECTION,
6 MOD OR 5 MOD w CXC SUP.
NTS
TB1
TB2
J3
J4
P1
(REVERSIBLE)
AC INPUT KNOCKOUT PLATE
AC INPUTS
ACCEPTS 3/4" FITTING/CONDUIT
1.125" KO
ACCEPTS 1/2" FITTING/CONDUIT
#1/4-20 CHASSIS GROUND
0.875" KO
DC OUTPUT
TIGHTEN TO 8 FT-LB
USES 1/4-20 x 5/8" OUTPUT LUGS
PIN OUT (J4)
CAN IN RJ12 OFFSET
PIN OUT (J3)
CAN OUT RJ12 OFFSET
)
4. CAN L
6. NOT CONNECTED
5. NOT CONNECTED
J3
J4
E2 COMMON (+)
LIST 0,6,81 - 6 MODULE , DUAL FEEDS
1. GND
2. CAN H
3. NOT CONNECTED
E1 LIVE ( -
