Alpha Technologies Cordex 48-1kW 19 6000W - Manual (Page 43)

19.00 482.6
6.98 177.3
18.31 465.1
0
1.485 37.72
3.235 82.17
3.735 94.87
5.485 139.32
PLAN VIEW
TOP VIEW
0
17.50
444.5
18.25
463.5
(-).75
19.0
0
11.95 303.4
(-) .74 18.8
P/N 010-566-20
48V-1kW CXRC
P/N 018-557-20
CXCM SUPERVISORY
LIST 90 : MODULE BLANK
FRONT ISOMETRIC VIEW
REAR ISOMETRIC VIEW
.875 K.O ACCEPTS 3/4" CONDUIT
1.125 K.O. ACCEPTS 1" CONDUIT
SIZE DWG NO. TYPE
B
SHEET
TITLE
ISSUE
DATE OF
TOLERANCES
SCALE
APPROVED
CHECKED
DRAWN
DESIGN MATERIAL
FINISH
FOR MANUFACTURING WITHOUT ITS WRITTEN CONSENT.
ARGUS TECHNOLOGIES AND SHALL NOT BE COPIED OR USED
THESE DESIGNS AND SPECIFICATIONS ARE THE PROPERTY OF
REVISIONS
LTR DESCRIPTION APPD DATE
REV
X.X 0.04"
X.XX 0.02"
X.XXX 0.01"
[X] 1mm
[X.X] 0.5mm
[X.XX] 0.25mm
030-707-06
OUTLINE, 19 FLUSH MOUNT CABINET
5 MDL w CXCM SUP. OR 6 MDL
48-1kW CXRC
PER P.O. and
Doc. 070-024-83
1 1
DGW
DGW
2003/11
2003/11
D2
c 2003 ARGUS TECHNOLOGIES O
A
DIMENSIONS ARE IN INCHES WITH METRIC [mm] IN BRACKETS: INCHES [mm]
....
...
NTS
REV BY
