c 2004 ARGUS TECHNOLOGIES
JUMPER SETTING FOR P1
CAN TERMINATED
CAN UNTERMINATED
TB1
TB2
PIN OUT (J3)
)
(REVERSIBLE)
AC INPUT KNOCKOUT PLATE
AC INPUTS
ACCEPTS 3/4" FITTING/CONDUIT
1.125" KO
ACCEPTS 1/2" FITTING/CONDUIT #1/4-20 CHASSIS GROUND
0.875" KO
(707-340-20)
CXCM BACKPLANE
DC OUTPUT
LIST 0,6 : 5 MODULE WITH CXC CONTROLLER
TIGHTEN TO 8 FT-LB
USES 1/4-20 x 5/8" OUTPUT LUGS
E2 COMMON (+)
6. NOT CONNECTED
4. CAN L
5. NOT CONNECTED
3. NOT CONNECTED
1. GND
2. CAN H
CAN OUT RJ12 OFFSET
E1 LIVE ( -
TB2 FEEDS RECTIFIERS 2,4
TB1
#6-32 SCREWS
L1
TYPICAL AC INPUT TERMINAL BLOCK
(TB1 SHOWN)
TB1 FEEDS RECTIFIERS 1,3,5
L2/N
P1
J3
P1
J3
2004/12
SIZE DWG NO. TYPE
B
SHEET
TITLE
ISSUE
DATE
OF
TOLERANCES
SCALE
APPROVED
CHECKED
DRAWN
DESIGN MATERIAL
FINISH
FOR MANUFACTURING WITHOUT ITS WRITTEN CONSENT.
ARGUS TECHNOLOGIES AND SHALL NOT BE COPIED OR USED
THESE DESIGNS AND SPECIFICATIONS ARE THE PROPERTY OF
REVISIONS
LTR DESCRIPTION APPD DATE
REV
B
SDW
DGW
REV BY
UPDATED AC I/P TERM BLOCK
ADDED PG3, LIST0,9,82, 3 FEEDS
NTS
C
0.01"
0.04"
X.XXX
0.02"
X.X
X.XX
0.25mm
030-707-08
[X.XX]
48-1kW CXRC 19" FLUSH MNT
6 MOD OR 5 MOD w CXC SUP.
Doc. 070-024-83
1 4
DGW
DGW
2004/05
2004/05
D2 C DIMENSIONS ARE IN INCHES WITH METRIC (mm) IN BRACKETS: INCHES [mm]
JK 2004/05
WES 2004/05
[X] 1mm
[X.X] 0.5mm
CUSTOMER CONNECTION,
PER P.O. and
GS
