Preface

Dear Customer,

Thank you for purchasing this photo-electric radio

smoke detector. You made the right decision in choo-

sing this state-of-the-art technology, which complies

with the current standards of domestic and European

regulations. The CE has been proven and all related

certifications are available from the manufacturer

upon request. To maintain this status and to guaran-

tee safe operation, it is your obligation to observe

these operating instructions! In the event of questions,

please contact your local specialist dealer. The radio

smoke detector reacts to visible smoke particles. If

too much smoke reaches its measuring chamber,

an alarm is triggered (direct on the detector and on

the alarm centre). If integrated into the ABUS radio

alarm system, the radio smoke detector occupies a

zone that is monitored even if the system is inactive.

The radio smoke detector is used in locations with

low dust pollution (residential buildings, offices) or

where thick smoke can be expected in the event of a

fire (such as smouldering furniture).

Read carefully the notes and advice in these opera-

ting instructions! If you do not follow these instruc-

tions, your guarantee claim becomes invalid! We can

accept no liability for the consequences! No part of

the product may be changed or modified in any way.

Important

Smoke detectors cannot be used to prevent fire. They

are used merely to react to specific fire characteris-

tics. During installation, make sure that the detector

is placed in accordance with local fire precaution

regulations and recommendations. These regulations

can vary from country to country. For more detailed

information, contact your local fire authorities.

Selecting the installation location

Place the smoke detector directly on the ceiling in

the centre of the room. The minimum distance to

each side wall should be 12 cm. We recommend a

separate smoke detector for each entrance area,

staircase, living-room and bedroom. The distance

between two smoke detectors should not exceed 8

metres. Install smoke detectors in a position with the

best available transmission and reception properties.

Use double-sided adhesive tape to fix the detec-

tor temporarily in different locations and test it by

triggering an alarm. If it is not detected by the alarm

centre, move the detector to a new position.

Do NOT install the detector:

– Places with greater temperature variation than the

ambient operating temperature range

– Places where draughts can keep smoke away

from the detector (such as near windows, doors or

ventilation shafts)

– Places with steam, high air humidity or exhaust

gases (kitchen, bathroom, garage, loft)

– Places where thick dust or smoke could impair the

function of the smoke detector.

– At the highest point of a gable roof. The distance to

the rooftop should be at least 30cm.

– Near large metal structures

Installation

1. Important: Do not insert batteries until you train

the detector.

2. Remove the locking pin securing the mounting

bracket to the unit.

3. Remove the detector from the detector base. Do

this by turning the base anticlockwise.

4. Install the smoke detector at the selected location.

Screw the detector base to the ceiling.

a. Use the base to mark drill-hole positions. Use

the existing blanks.

b. Use screws and wall plugs to fix the detector base.

5. Make sure that the detector base lies flat on the ceiling.

6. Open the battery housing and place the two lithi-

um batteries provided in the battery clip. Check for

correct battery polarity.

7. Fix the sensor to the detector base and turn it

clockwise to fix it into place. The detector has a

safety device that prevents installation without a

battery.

8. Insert the locking pin in order to secure the moun-

ting bracket to the detector. Test the alarm.

Learning

To use the detector, you first have to train it on the

ABUS radio alarm centre. Proceed as follows:

1. Switch the alarm centre to learn mode. You see

the message “Scanning for signal” on the display.

2. Write message is sent automatically, 10 seconds

after installing the batteries, or by pressing the

detector‘s tamper for a period of 3 seconds.

3. Check that the alarm system has recognised the

radio smoke detector.

4. Switch the alarm centre back to normal operating mode.

5. To repeat training, remove the batteries and

replace them after about 30 seconds.
