ABUS FU8370 Secvest 2WAY Wireless Glass Breakage Detector - Manual (Page 15)

15
Weight 140 g
HF immunity 10 V/m
Power supply 3.0 V DC (lithium CR2 battery)
“Low battery” error
message
< 2.4 V
Frequency 868.6625 MHz
HF transmission power 10 mW (antenna input)
Tamper monitoring Yes
Supervision monitoring Every 4 minutes
Housing material ABS
Subject to alterations and errors.
Position
The detector has a sensor that monitors the entire room
(360°), though it should not directly face the area to be
monitored. It is designed for installation on walls and
ceilings.
Ideally, the detector should be installed on the wall opposite
the window. The ceiling or side walls are also suitable
locations.
The best position is approx. 2-3 metres from the window
pane. Maintain a distance of at least 1.2 metres to other
