Anschließen der Sabotagelinie
Gehtest
Die Reichweite des Detektors wird ohne die Frontabdeckung erhöht. Daher muss diese beim
korrekten Ausrichten des Sensors und beim Prüfen der Ausgänge angebracht sein. Passen
Sie die Reichweite anhand der nachfolgenden Tabelle an und schwenken und neigen Sie das
Abb. 7
Alternative 1
Alternative 2
Alternative 3 (nicht empfohlen)
