ABUS AZBW20000 Outdoor motion detector User Manual
Page 28
Technical data
Detection area
Programmable between 10 and 30 metres.
Cover
10–70° detection angle, 30 m × 30 m maximum cover.
Adjustment
180° panning + 90° tilting
Cover for reducing the area (if required).
Fresnel lens
28 zones per pyro pair that can be masked with shutters or special
tape (supplied).
Customer-specific
appearance
Double-shielded silicon quad element absorbs 50,000 lux white light
Outputs
Magnetically protected, quiet semi-conductor relay.
Output 1 NO
Volt free relay contact 24 V AC/DC at 50 mA with integrated 25R
series resistance, NO, alarm duration 10 seconds
Output 2 NC
Volt free relay contact 24 V AC/DC at 50 mA with integrated 25R
series resistance, NC, alarm duration 10 seconds
Connected load
9 to 15 V DC.
Current
8 mA (12 V nominal).
Pulse counter
1–2
Temperature
compensation
Temperature-dependent, digital adjustment.
Control
Digital microprocessor – non-volatile memory.
