M u l t i - T o u c h P a n e l P C A C P - 1 1 0 3
Chapter 2 Hardware Installation 2-16
Pin Pin Name Signal Type Signal Level
1 BKL_PWR PWR +5V / +12V
2 BKL_CONTROL OUT
3 GND GND
4 GND GND
5 BKL_ENABLE OUT +5V
2.20 DDR3 SODIMM Slot (DIMM1)
Standard specification
2.21 Mini Card Slot (mSATA function only)
Pin Pin Name Signal Type Signal Level
1 NC
3 NC
5 NC
7 NC
9 GND GND
11 NC
13 NC
15 GND GND
17 NC
19 NC
21 GND GND
23 mSATA_RX+ DIFF
