AAEON ACP-1103 User Manual
Page 34
M u l t i - T o u c h P a n e l P C
A C P - 1 1 0 3
Chapter 2 Hardware Installation
2-13
5
GND
GND
2.16 USB 2.0 Port 4 (CN27)
Pin
Pin Name
Signal Type
Signal Level
1
+5V
PWR
+5V
2
USB4_D-
DIFF
3
USB4_D+
DIFF
4
GND
GND
5
GND
GND
6
WIR_DIS
SINGLE
2.17 18-bits LVDS Output (CN15)
Pin
Pin Name
Signal Type
Signal Level
1
BKL_ENABLE
OUT
3
LCD_PWR
+3.3V/+5V
5
LVDS_A_CLK-
DIFF
7
LVDS_A_CLK+
DIFF
