M u l t i - T o u c h P a n e l P C A C P - 1 1 0 3
Chapter 2 Hardware Installation 2-4
2.3 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Label Function
JP2 Clear CMOS
JP3 LVDS Voltage Selection
JP5 Inverter Power Selection
JP6 AT/ATX MODE SELECT
