S u b C o m p a c t B o a r d G E N E - 5 3 1 5
Chapter 2 Quick Installation Guide 2 - 30
19 DA1 44 DACK#
20 DA0 45 DASP#
21 D0 46 PDIAG#
22 D1 47 D8
23 D2 48 D9
24 IO16# 49 D10
25 Ground 50 Ground
2.41 Mini-PCI Slot (MPCI1)
Standard Specification
2.42 DDR SODIMM Slot (DIMM1)
Standard SODIMM Slot
Note from AMD:
Memory configurations supported. Only one DIMM or SODIMM is
supported as long as the configuration requirements are met.
Devices Max
Memory
1
Max GLIU
Frequency
GLCP 4C00000Fh
Upper Bits/Lower Bits
GLMC
2000001 Ah
Bits【26:24】
4 512M 400MHz
F2F100FFh/
56960004h
4
8 1G 400MHz
F2F100FFh/
56960004h
4
4 512M 333MHz
F2F100FFh/
56960004h
3
8 1G 333MHz F2F100FFh/ 56960004h 3
16 2G 333MHz F2F100FFh/ 56960004h 3
1: Maximum memory is assuming 1Gbit devices.
