S u b C o m p a c t B o a r d G E N E - 5 3 1 5
Chapter 2 Quick Installation Guide 2 - 29
Note: An APM Mode limitation, OS (Operating System) recognizes serial
port 5 & 6 of GENE-5315 Rev.B but is reverse. OS will reassign IRQ
and give sequence of serial port 5 & 6 after uninstalling all of serial ports
and second time boots in OS.
2.39 External Battery (BAT1)
Pin Signal
1 VBAT (+3 Volt.)
2 Ground
2.40 Compact Flash Disk Slot (CFD1)
Pin Signal Pin Signal
1 Ground 26 Ground
2 D3 27 D11
3 D4 28 D12
4 D5 29 D13
5 D6 30 D14
6 D7 31 D15
7 CS#1 32 CS#3
8 Ground 33 Ground
9 Ground 34 IOR#
10 Ground 35 IOW#
11 Ground 36 +5 Volt.
12 Ground 37 IRQ14
13 +5 Volt. 38 +5 Volt.
14 Ground 39 CSEL#
15 Ground 40 N.C.
16 Ground 41 RESET#
17 Ground 42 IORDY
18 DA2 43 DREQ
