Text mode
Original mode

S u b C o m p a c t B o a r d

G E N E - 5 3 1 5

Chapter 2 Quick Installation Guide

2 - 15

5 D6

6 D9

7 D5

8 D10

9 D4

D11

11 D3

12 D12

13 D2

14 D13

15 D1

16 D14

17 D0

18 D15

19 Ground

20 N.C.

21 DREQ

22 Ground

23 IOW#

24 Ground

25 IOR#

26 Ground

27 IORDY

28 Ground

29 DACK#

30 Ground

31 IRQ14

32 N.C.

33 DA1

34 PDIAG#

35 DA0

36 DA2

37 CS#1

38 CS#3

39 Active

LED#

40 Ground

41 +5Volt.

42 +5Volt.

43 Ground

44 N.C.

Note: The IDE interface on GENE-5315 supports two IDE devices

including CF card. If you use a CF card, GENE-5315 allows one IDE

device.

2.14 Floppy Connector (CN2)

Pin Signal

Pin

Signal

1 Ground

2 DENSEL#

3 Ground

4 N.C.

5 Ground

6 N.C.
