S u b C o m p a c t B o a r d G E N E - 5 3 1 5
Chapter 2 Quick Installation Guide 2 - 23
25 R0 26 R1
27 R2 28 R3
29 R4 30 R5
31 R6 32 R7
33 Ground 34 Ground
35 Clock 36 VSYNC
37 DE 38 HSYNC
39 N.C. 40 N.C.
For 18-bit TFT LCD
Pin Signal Pin Signal
1 +5Volt. 2 +5Volt.
3 Ground 4 Ground
5 +3.3Volt. 6 +3.3Volt.
7 N.C. 8 Ground
9 N.C. 10 N.C.
11 B0 12 B1
13 B2 14 B3
15 B4 16 B5
17 N/C 18 N/C
19 G0 20 G1
21 G2 22 G3
23 G4 24 G5
25 N.C. 26 N.C.
27 R0 28 R1
29 R2 30 R3
31 R4 32 R5
33 Ground 34 Ground
35 Clock 36 VSYNC
